TM236VCS01 30 Pins 23.6 Inch 1920*1080 LCD Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | AVIC |
| Model Number: | TM236VCS01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | TM236VCS01 | Screen Size: | 23.6" |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080, FHD 93PPI | Active Area(mm): | 521.28(W)×293.22(H) Mm |
| Outline Size: | 544.8(W)×320.5(H)×19.2(D) Mm | Viewing Angle: | 85/85/80/80 (Typ.)(CR≥10) |
| Display Colors: | 16.7M 72%NTSC | Used For: | Desktop Monitor |
Product Description
TM236VCS01 30 Pins 23.6 Inch 1920*1080 LCD Screen
TM236VCS01 Product details :
| Brand | AVIC |
| Model P/N | TM236VCS01 |
| Diagonal Size | 23.6" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD 93PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 521.28(W)×293.22(H) mm |
| Bezel Opening | - |
| Outline Size | 544.8(W)×320.5(H)×19.2(D) mm |
| Treatment | Antiglare |
| Luminance | 300 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Response | 1.3/3.5 (Typ.)(Tr/Td) ms |
| Good View at | - |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 16.7M 72%NTSC |
| Backlight | 4 pcsCCFL, 50K hours, No Driver |
| Mass | 3.25Kgs (Typ.) |
| Used for | Desktop Monitor |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit), 30 pinsConnector |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
