new TM070DDH01 40 Pins 7.0 Inch LCD Screen LCD Display
Product Details:
| Place of Origin: | China |
| Brand Name: | TIANMA |
| Model Number: | TM070DDH01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | TM070DDH01 | Screen Size: | 7.0" |
|---|---|---|---|
| Pixel Number: | 1024(RGB)×600, WSVGA 169PPI | Active Area(mm): | 153.6(W)×90(H) Mm |
| Bezel Area(mm): | 156.2(W)×92.6(H) Mm | Viewing Angle: | 75/75/70/75 (Typ.)(CR≥10) |
| Display Colors: | 16.7M 50%NTSC | Used For: | Digital Photo Frame、Portable DVD Player |
Product Description
new TM070DDH01 40 Pins 7.0 Inch LCD Screen LCD Display
TM070DDH01 Product details :
| Brand | TIANMA |
| Model P/N | TM070DDH01 |
| Diagonal Size | 7.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1024(RGB)×600, WSVGA 169PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 153.6(W)×90(H) mm |
| Bezel Opening | 156.2(W)×92.6(H) mm |
| Outline(mm) | 165.75 × 105.39× 3.7 (H×V×D) |
| Treatment | Antiglare |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle | 75/75/70/75 (Typ.)(CR≥10) |
| Response | 20 (Typ.)(Tr+Td) ms |
| Good View at | 12 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 16.7M 50%NTSC |
| Backlight | 3S6PWLED, 20K hours, No Driver |
| Mass | TBD |
| Used for | Digital Photo Frame,Portable DVD Player |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 8-bit), 40 pins FPC |
| Voltage Supply | 3.3/11/20/-6.8V (Typ.)(VDD/AVDD/VGH/VGL) |
| Max. Ratings | Storage Temp.: -30 ~ 70 °C Operating Temp.: -20 ~ 60 °C |
TM070DDH01 Shipment:
When you place an order, please choose a shipping method and pay for the order including the shipping fee. We will send the items within 3 days once your payment is completed.We do not uarantee delivery time on all international shipments due to differences in customs clearing times in individual countries, which may affect how quickly your product is inspected.
TM070DDH01 Payment:
1.- Please make sure your payment account is available before you bid the item.
2.- All payments should be cleared within 7days after you receive the item. If you really have difficulty in paying the item,please contact us firstly, we will help to solve it.
3.- If you have any special request about the details of item, please leave a note in your order.
TM070DDH01 Shipping Information:
We ship to worldwide by DHL,UPS,FEDEX,TNT,EMS ,Normal airmail and agency. It depends on buyer’s requirements.
Delivery Time: We will ship the items within 2 working days after receive the payment.
TM070DDH01 Warranty & Return Policy:
We offer 3month warranty for all parts. If meet any quality problems within 3month, please contact us on time, we will solve it immediately .We sincerely look forward to establishing long term business relationship with you in the future. If anything we can do for you, just fell free to contact us at your convenience.
TM070DDH01 FAQ:
Q: I do not find the LCD I am looking for in the website, what should I do ?
A: You can give us some pictures,we have a lot of LCD out of shelves.
Q: How long will I receive my goods of TM070DDH01 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment for TM070DDH01 ?
A: We accept T/T , Paypal , western union .
Q: What happen if the TM070DDH01 I receive can't work ?
A: TM070DDH01 will be tested strictly before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
TM070DDH01 Shippment & Packing
