5.0 inches 480*800 lcd screen Display HSD050C8W1-A00-0220 lcd monitors
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD050C8W1-A00-0220 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD050C8W1-A00-0220 | Screen Size: | 5.0" |
|---|---|---|---|
| Pixel Number: | 480(RGB)×800, WVGA 188PPI | Active Area(mm): | 64.8(W)×108(H) Mm |
| Luminance: | 0 Cd/m² | Contrast Ratio: | 700:1 (Typ.) (TM) |
| Work Mode: | TN, Normally White, Transmissive | Used For: | Mobile Phone |
| Display Colors: | 16.7M 60%NTSC | Environment: | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
Product Description
5.0 inches 480*800 lcd screen Display HSD050C8W1-A00-0220 lcd monitors
HSD050C8W1-A00-0220 Product details :
| Brand | HannStar |
| Model P/N | HSD050C8W1-A00-0220 |
| Diagonal Size | 5.0" |
| Panel Type | a-Si TFT-LCD, CELL, COG |
| Resolution | 480(RGB)×800, WVGA 188PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 64.8(W)×108(H) mm |
| Bezel Opening | - |
| Outline Size | 68.4(W)×115.9(H)×1.23(D) mm |
| Surface | - |
| Brightness | 0 cd/m² |
| Contrast Ratio | 700:1 (Typ.) (TM) |
| Viewing Angle | 70/70/70/60 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 12 o'clock |
| Response Time | 4/12 (Typ.)(Tr/Td) |
| Glass Depth | 0.40+0.40 mm |
| Transmissivity | 5.16% (Typ.)(with Polarizer) |
| Display Colors | 16.7M 60%NTSC |
| Lamp Type | No B/L |
| Frequency | - |
| Touch Screen | Without |
| Driver IC | COG Built-in NT35510 |
| Panel Weight | - |
| Application | Mobile Phone |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
HSD050C8W1-A00-0220 Paramenters:
* every item is as the picture showed and the title description.
* if you have any problem with the item, please contact me before you buy it, we will reply to you as soon as possible
* Each item has been checked and in good condition before shipping.
* It is shipped in protective bubble wrap and has all the protective screen coatings, so, please do not worry.
* if the item has some problem, please contact us at first time. I will help you solve problems and try our best to make you be satisified.
* happy do business with you, i think communication will solve all the problem .so, please do not be hesitate to contact us.
HSD050C8W1-A00-0220 Our superiority:
1.Superior Quality ;
2.On-time delivery;
3.Best Pre/after sale Service
HSD050C8W1-A00-0220 Shippment & Packing
1. We will ship all your order within 3-5 working days after receiving your payment. Otherwise, we will state it in the invoice in advance.
2.We can Ship via your shipping account (DHL / FEDEX / UPS / TNT or others) as your instruction.
HSD050C8W1-A00-0220 Warranty:
100% NEW AND ORIGINAL
30-90 DAYS QUALITY WARRANTY
1. Quality and reliability are of highest importance to us, our parts could accept any kinds of testing.
2.You will receive a 30-90 days form, fit, and function of part warranty to make sure you receive exactly what you ordered.
3. If the item is defective upon receipt, it should be within 7days from the date of receipt for exchange a new one (Buyer should return all original and undamaged items under re-saleable condition).
HSD050C8W1-A00-0220 FAQ:
Q: Can I pay my goods HSD050C8W1-A00-0220 by credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How do you ship my goods HSD050C8W1-A00-0220 ?
A: We can shipping all over the world.via DHL,UPS,Fedex and EMS.
Q: Can you give me a discount if I need a large quantity of HSD050C8W1-A00-0220 ?
A: Of course!If you make a large order, we will give you a discount.
Q: I do not find the LCD I am looking for in the website, what should I do ?
A: You can give us some pictures,we have a lot of LCD out of shelves.
Q: How long will I receive my goods of HSD050C8W1-A00-0220 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
