21.5 inches 1080p lcd screen Display M215HW03 V1 CELL
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | M215HW03 V1 CELL |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | M215HW03 V1 CELL | Screen Size: | 21.5" |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080, FHD 102PPI | Active Area(mm): | 476.64(W)×268.11(H) Mm |
| Outline(mm): | 488.22(W)×282.91(H)×1.9(D) Mm | Luminance: | 0 Cd/m² |
| Support Color: | 16.7M 72% NTSC | Used For: | Desktop Monitor |
| Contrast Ratio: | 1000:1 (Typ.) (TM) | Treatment: | Antiglare, Hard Coating (3H) |
Product Description
21.5 inches 1080p lcd screen Display M215HW03 V1 CELL
M215HW03 V1 CELL Product details :
| Brand | AUO |
| Model P/N | M215HW03 V1 CELL |
| Diagonal Size | 21.5" |
| Panel Type | a-Si TFT-LCD, CELL, FOB |
| Resolution | 1920(RGB)×1080, FHD 102PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 476.64(W)×268.11(H) mm |
| Bezel Opening | - |
| Outline Dim. | 488.22(W)×282.91(H)×1.9(D) mm |
| Luminance | 0 cd/m² |
| View Direction | 6 o'clock |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Plate Thickness | 0.70+0.70 mm |
| Support Color | 16.7M 72% NTSC |
| Weight | 545g (Typ.) |
| Frame Rate | 60Hz |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Response Time | 3.8/1.2 (Typ.)(Tr/Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Transmittance | 5.8% (Typ.)(with Polarizer) |
| Light Source | No B/L |
| Designed For | Desktop Monitor |
| Touch Panel | Without |
| D-IC Detail | COF Built-in 6 source chips |
| Interface Type | LVDS (2 ch, 8-bit)30 pins Connector |
| Power Supply | 5.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C |
M215HW03 V1 CELL Payment Opinions:
1.T/T (Wire Transfer)
2 WESTERN UNION
3.PAYPAL
4.Alipay for payment
Please inform us if you have a prefer payment way.
M215HW03 V1 CELL Shippment & Packing
M215HW03 V1 CELL Shipping details:
& we must test the product strictly before shipping in order to ensure that the interests of consumers.
& We will ship the items within 2 working days after receive the payment.
& We can ship to you by DHL/ UPS/EMS/Fedex. Please contact us and we will use your preferred ways.
& we only ship according to the shipping address unless you contact us to change it.
& As to the shipping time,it usually will be 3-15 days,which will be different for different countries.
M215HW03 V1 CELL Buyer Reading:
1.Please confirm receipt of products if the items you received, and if the goods was damaged please contact us immediately. send the photo to us that we can check and give you best solution.
2.We only guarantee delivery in time but we couldn't control the express delivery time. Our related sales person will be responsible to send the AWB for the delivered goods in the next workday. you can check the AWB in the website which we send to you. For the AWB you also can call to the local branch of the express company in your company.
If you have any other questions please feel free to contact us in anytime !
looking forward to doing more business with you
M215HW03 V1 CELL FAQ:
Q: Can you tested the M215HW03 V1 CELL before shipping ?
A: Of course , our lcd panel M215HW03 V1 CELL was Strictly tested before shipping.
Q: How to order M215HW03 V1 CELL ?
A: We accept T/T , Paypal , western union .
Q: What happen if the lcd panel M215HW03 V1 CELL received can't work ?
A: M215HW03 V1 CELL was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
Q: Are you manufactory or trade company?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
