7.0 inches 1024*600 lcd panel TM070DDH05 LCD screen for Portable Navigation
Product Details:
| Place of Origin: | China |
| Brand Name: | TIANMA |
| Model Number: | TM070DDH05 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | TM070DDH05 | Screen Size: | 7.0" |
|---|---|---|---|
| Pixel Number: | 1024(RGB)×600, WSVGA 169PPI | Active Area(mm): | 153.6(W)×90(H) Mm |
| Outline(mm): | 165.75×105.39×2.5 (H×V×D) | Bezel Opening: | 156.2(W)×92.6(H) Mm |
| Used For: | Pad & Tablet、Portable Navigation、Digital Photo Frame、Portable DVD Player、MID UMPC | Refresh Rate: | 60Hz |
| Signal Type: | LVDS (1 Ch, 6/8-bit), FPC40 Pins | Max. Ratings: | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
Product Description
7.0 inches 1024*600 lcd panel TM070DDH05 LCD screen for Portable Navigation
TM070DDH05 Product details :
| Brand | TIANMA |
| Model P/N | TM070DDH05 |
| Diagonal Size | 7.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1024(RGB)×600, WSVGA 169PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 153.6(W)×90(H) mm |
| Bezel Opening | 156.2(W)×92.6(H) mm |
| Outline (mm) | 165.75×105.39×2.5 (H×V×D) |
| Treatment | Antiglare |
| Luminance | 300 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle | 75/75/70/75 (Typ.)(CR≥10) |
| Response | 20 (Typ.)(Tr+Td) ms |
| Good View at | 12 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 262K/16.7M 50%NTSC |
| Backlight | 3S8PWLED, 15K hours, No Driver |
| Mass | 84.0g |
| Used for | Pad & Tablet,Portable Navigation,Digital Photo Frame,Portable DVD Player,MID UMPC |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 6/8-bit), FPC40 pins |
| Voltage Supply | 3.3/11.0/16.0/-6.8V (Typ.)(VDD/AVDD/VGH/VGL) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
(New & Original) TM070DDH05:
Thank you to choose our product extremely.
We will provide you with the best quality and most cost-effective products.
Our aim is to perfect the product quality for a long-time business.
So, please rest assured to choose, please contact us if have any questions.
TM070DDH05 Useful messages:
We offer high quality, fast delivery, competitive price for our customers;
1. Please send your RFQ(request for quoting) to get latest price;
2. we will ship it in 1-3 working days after your paying
3. We can ship to you by UPS/DHL//EMS/Fedex. Please contact us and we will use your preferred ways;
4. We have a large stock and the prices are variable,If needed please contact us.
TM070DDH05 About Payment Terms:
1. You can pay for your purchase order by PayPal, T/T, Western Union or Cash.
2. The unit price we provided not included any shipping fees or payment charges.
3. We are not responsible for any import fees or customs taxes.
TM070DDH05 Shippment & Packing
TM070DDH05 About Shipment Terms:
1. We will pack and send your goods 1-3 working days after we confirmed your payment. For quickly packing and sending, please let us know if you finished the payment.
2. We need your shipping information including your name, address and phone number for shipping your parcel.
3. Tracking number will be shared with you when we got it from the logistics company.
TM070DDH05 FAQ:
Q: Do you accept sample orders of TM070DDH05 ?
A: Of course! Sample order is welcome.
Q: Can I pay my order of TM070DDH05 vai credit card?
A: Yes! You can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90 days warranty.
Q: If I place order now, when will you ship the goods of TM070DDH05 ?
A: The order will be shipped within 2-3 working days after received your payment.
