G121SN01 V.1 12.1 inch LCD Module 800*600 Applied to industrial products
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | G121SN01 V1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | G121SN01 V1 | Screen Size: | 12.1 Inch |
|---|---|---|---|
| Pixel Number: | 800(RGB)×600, SVGA, 82PPI | Display Area: | 246(W)×184.5(H) Mm |
| Outline(mm): | 279(W)×209(H)×11(D) Mm | Contrast Ratio: | 500:1 (Typ.) (TM) |
| Display Colors: | 262K , 55% NTSC | Used For: | Industrial |
Product Description
G121SN01 V.1 12.1 inch LCD Module 800*600 Applied to industrial products
G121SN01 V1 Product details :
| AUO LCD SCREEN G121SN01 V1 | |
| Panel Brand | AUO |
| Panel Model | G121SN01 V1 |
| Panel Size | 12.1 inch |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 800(RGB)×600, SVGA, 82PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 246(W)×184.5(H) mm |
| Bezel Opening | 249.05(W)×188.3(H) mm |
| Outline Size | 279(W)×209(H)×11(D) mm |
| Brightness | 200 cd/m² (Typ.) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Viewing Angle | 70/70/60/50 (Typ.) (CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 12 o'clock |
| Response Time | 10/25 (Typ.)(Tr/Td) |
| Display Colors | 262K , 55% NTSC |
| Lamp Type | 2 pcs CCFL , 50K hours, without driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 640g (Typ.) |
| Application | Industrial |
| Signal Interface | LVDS (1 ch, 6-bit) , 20 pins , terminal |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -10 ~ 65 °C ; Storage Temp.: -30 ~ 70 °C |
| G121SN01 V.1 12.1 inch LCD Module 800*600 Applied to industrial products | |
G121SN01 V1 About Shipping:
We will test them strictly before shipping.
We will ship it in 3 working days after your paying.Buyer is responsible for customs duty fee.
It usually takes 10-45 business days for international shipping.If you don't receive the parcel for a long time,pls contact with us.
G121SN01 V1 Logistics:
1. Worldwide shipping.
2. Orders will be delivered in 3 working days after receiving full payment.
3. Major express partners: DHL, Fedex, TNT, EMS, Aramex.
4. We are not responsible for any customs duties and additional taxes.
G121SN01 V1 Tips that Will help:
For Brazil buyers, if you select Express shipping, like FED DHL UPS Ect. Please do provide company name and CNPJ number or CPF Number.
Please check your messages often, we may have some issues need your confirmation before shipping.
Please provide your FULL NAME for shipping.
Make the selection if the product has parameters, or note in the order.
Chile, Argentina buyers please provide your Tax number for express shipping like UPS.
The "Estimated Delivery Time" given by aliexpress is NOT correct, NOT our guaranteed time.
Postal mail is cheap but not fast, especially for some remote countries. If you are urgent, please inquiry faster methods.
If ship by express, make sure you are NOT in remote area, or extra costs needed, and please note that it is for remote pleace delivery : Charged by Logostics Company !
Tracking number is available for every package. Track here: www.17track.net/index_en.shtml.
Standard batteries, liquid and other prohibited parts are usually removed before shipping if your item are these , we may shipped by Special Line which will charged extra dollars
Customs, Duties and Import Fees are the buyer's responsibilities. We are not responsible for customs delays or any duties, tariffs, Value-Added Tax (VAT) or other fees which may be incurred with your purchase. Be know your customs policy.
G121SN01 V1 FAQ:
Q: What happen if the lcd panel G121SN01 V1 I received can't work ?
A: our lcd panel G121SN01 V1 was tested ok before shipping .
Q: How to order lcd panel G121SN01 V1 ?
A: Tell us the quantity you need ,Then we will make a PI for you to confirm the order details ,When we confirmed everything, you can arrange the payment ,After we received the payment, we will ship goods to you within 1-2day.
Q: Can you declared low value for my order lcd screen G121SN01 V1 when shipping?
A: Yes, We can do it for you if you need.
Q: How long is the warranty of 12.1 inch G121SN01 V1 ?
A: 90 days .
G121SN01 V1 Shippment & Packing
