G101UAN02.0 Industrial IPS AUO 10.1 inch TFT LCD display with 1920*1200 RGB lcd pane
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | G101UAN02.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | G101UAN02.0 | Panel Size: | 10.1 Inches |
|---|---|---|---|
| Resolution: | 1920(RGB)×1200, WUXGA, 224PPI | Display Area: | 216.81(W)×135.5(H) Mm |
| Outline Size: | 229.4(W)×150.5(H)×5.05(D) Mm | Viewing Angle: | 89/89/89/89 (Typ.) (CR≥10) |
| Display Colors: | 16.7M , 50% NTSC | Application: | Industrial Outdoor High Brightness |
Product Description
G101UAN02.0 Industrial IPS AUO 10.1 inch TFT LCD display with 1920*1200 RGB lcd pane
G101UAN02.0 Product details :
| AUO LCD SCREEN G101UAN02.0 | |
| Panel Brand | AUO |
| Panel Model | G101UAN02.0 |
| Panel Size | 10.1 inches |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1920(RGB)×1200, WUXGA, 224PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 216.81(W)×135.5(H) mm |
| Outline Size | 229.4(W)×150.5(H)×5.05(D) mm |
| Surface | Hard coating, anti-reflection treatment |
| Brightness | 800 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (Transmission) |
| Viewing Angle | 89/89/89/89 (Typ.) (CR≥10) |
| Display Mode | AHVA, Normally Black, Transmissive |
| Response Time | 25 (Typ.)(Tr+Td) ms |
| Display Colors | 16.7M , 50% NTSC |
| Lamp Type | 6S6P WLED , 20K hours, with LED driver |
| Frequency | 60Hz |
| Panel Weight | 170g (Max.) |
| Touch Screen | Without |
| Signal Interface | MIPI (4 data lanes) , 34 pins , terminal |
| Application | Industrial Outdoor High Brightness |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating temperature: -10 ~ 60 °C ; Storage temperature: -20 ~ 60 °C |
| G101UAN02.0 Industrial IPS AUO 10.1 inch TFT LCD display with 1920*1200 RGB lcd pane | |
G101UAN02.0 Dear customers:
Welcome to our YONGS Official Store .It's our honor to have this opportunity for providing services for you.
All of our products are in original high quality,they are new .
Please feel free to contact us no matter what product you want to buy.
If there is anything we can help you when you shopping in our store,
please contact us.
We will offer you the best service and happy shopping experience.
Hope we can have a good start cooperation.Thank you!
Best wishes
Yours
All members of YONGS Official Store
G101UAN02.0 Payment:
1:We receive papay payments. please make sure your address OK.
2: Payment must be made within 48 hours of the auction end time.
3: Non-Paying bidders will be reported.
G101UAN02.0 Note:
1: This product is a display screen, which needs to be installed by professionals. Please purchase with caution, thank you!
2: Purchasing this product, according to the buyer's choice of logistics, we will send it out within 48 hours, if there is a delay, please wait for the tracking information to prevail!
3: After receiving the product, if there is a problem, please contact customer service to solve it!
G101UAN02.0 Our advantages:
1: We are all own stock, with adequate supply
2: The quality of the product reached a series of certification
3: We support a variety of transportation, Hong Kong and the Chinese postal packets, EMS.DHL federal .UPS and TNT, can fully meet the different needs of the buyer.
G101UAN02.0 FAQ:
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: If I place order now,when will you ship the goods of G101UAN02.0 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How long will I receive my goods G101UAN02.0 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can I pay my order of G101UAN02.0 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
G101UAN02.0 Shippment & Packing
