G084SN05 V.8 8.4 inch LCD Module 800*600 Applied to industrial products
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | G084SN05 V8 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | G084SN05 V8 | Diagonal Size: | 7.4 Inch |
|---|---|---|---|
| Pixel Format: | 800(RGB)*480, WVGA, 133PPI | Active Area: | 170.4(H)*127.8(V) Mm |
| Outline Dim.: | 203(H)*142.5(V) *8.3(T) Mm | Luminance: | 450 Cd/m² (Typ.) |
| Support Color: | 262K/16.2M 45% NTSC | Designed For: | Industrial |
Product Description
G084SN05 V.8 8.4 inch LCD Module 800*600 Applied to industrial products
G084SN05 V8 Product details :
| AUO LCD SCREEN G084SN05 V8 | |
| Manufacturer | AUO |
| Model Name | G084SN05 V8 |
| Diagonal Size | 8.4 inches |
| Type | a-Si TFT-LCD, LCM |
| Pixel Number | 800(RGB)*600 SVGA 119PPI |
| Configuration | RGB Vertical Stripe |
| Display size | 170.4(H)*127.8(V) mm |
| physical dimension | 203(H)*142.5(V) *8.3(T) mm |
| Open area | 174.15(H)*131.2(V) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 450 cd/m² (Typ.) |
| Contrast Ratio | 600:1 (Typ.) (transmission) |
| Response Time | 20/10 (Typ.)(Tr/Td) ms |
| Viewing Angle | 80/80/80/60 (Typ.)(CR≥10) |
| Operating Mode | TN, normally white display, transmissive |
| Display Colors | 262K/16.2M, 45% NTSC |
| Best View on | 12 o'clock |
| Light Source | WLED [2 strings], 50K hours, with LED driver |
| Frame Rate | 60Hz |
| Touch Screen | Without |
| weight | 250±10g |
| Application | Industrial |
| Interface Type | 20 pins LVDS (1 ch, 6/8-bit), connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -30 ~ 85 °C |
| G084SN05 V.8 8.4 inch LCD Module 800*600 Applied to industrial products | |
G084SN05 V8 Contact Us:
1. If there's any problem, please do not hesitate to contact us by message, we will reply you within 1 business day. (Not include public holiday)
2. Working Hours: Monday to Saturday
3. If you don't get response within 1-2 business days, please check your email or My Messages in case your email provider has an overly aggressive spam filter blocking or my emails. Please add us in your contact and email us again.
4. Bulk order is acceptable, lower prices will be offered to you for bulk order.
G084SN05 V8 Our service:
> Fast delivery
> 90days warranty
> original,High quality
> Full tested before shipping.
G084SN05 V8 Warranty:
1.- 90days' warranty..
2.- If the item is defective upon receipt, it should be within 7days from the date of receipt for exchange a new one (Buyer should return all original and undamaged items under re-saleable condition)
3.- We supply free repairing service within one year of purchase. For the first 1 month, we will pay one way shipping cost( from us to your location); After 1 month of purchase, the buyer need to pay two ways of shipping cost.
4.- One we get the returned items, we will send the replaced ones back as soon as possible.
5.- Our warranty does not extend to any products that are physically damaged or under un-normal operating conditions as a result of misuse or improper installation on the parts
G084SN05 V8 Payment:
1. We accept Escrow, Alipay, Paypal, T/T(Bank Transfer), Credit Card, Western Union, Moneygram, etc....
2. If you have any problems of payment, please contact us.
G084SN05 V8 SHIPPING:
1 We will ship the items within 3working days after the payment is reached.
2 We often ship to customers by UPS/DHL/Fedex and ect,We would like to ship to you which is convenient to you. Please contact us directly and we will use your preferred ways.
3 We are not responsible for any accidents, delays or other issues that we couldn’t control, But we will contact the shipping company which is our long term cooperation.
4 Any import fees or charges are the buy’s responsibility.
G084SN05 V8 Refund&Return:
1. If the item is defective, pls notify us within 3 days after receiving.
2. items should be returned with original package if possible.
G084SN05 V8 FAQ:
Q: Can I pay my order of G084SN05 V8 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can you give me a discount if I need a large quantity of G084SN05 V8 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of G084SN05 V8 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How long is the warranty ?
A: We offer 90 days warranty .
G084SN05 V8 Shippment & Packing
