G070VVN01.0 7 inch 800*480 Suitable for industrial displays
Product Details:
Place of Origin: | China |
Brand Name: | AUO |
Model Number: | G070VVN01.0 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model: | G070VVN01.0 | Diagonal Size: | 7.0 Inch |
---|---|---|---|
Pixel Format: | 800(RGB)*480, WVGA, 133PPI | Active Area: | 152.4(W)*91.44(H) Mm |
Outline Dim.: | 164.55(H)*104.71(V) *11.8(T) Mm | Luminance: | 450 Cd/m² (Typ.) |
Support Color: | 262K/16.2M, 50% NTSC | Designed For: | Industrial |
Product Description
G070VVN01.0 7 inch 800*480 Suitable for industrial displays
G043FW01 V0 Product details :
AUO LCD SCREEN G070VVN01.0 | |
Manufacturer | AUO |
Model Name | G070VVN01.0 |
Diagonal Size | 7.0 inches |
Type | LCM, a-Si TFT-LCD |
Pixel Number | 800(RGB)*480, WVGA, 133PPI |
Configuration | RGB Vertical Stripe |
Display size | 152.4(W)*91.44(H) mm |
Bezel Area | 154.2(H)*93.24(V) mm |
Outline Dim. | 164.55(H)*104.71(V) *11.8(T) mm |
Surface | Matte, Hard coating (3H) |
Brightness | 450 cd/m² (Typ.) |
Contrast Ratio | 1500:1 (Typ.) (transmission) |
Response Time | 10/25 (Typ.)(Tr/Td) ms |
Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
Operating Mode | AMVA, normally black display, transmissive |
Support Color | 262K/16.2M, 50% NTSC |
Light Source | WLED [7S2P], 30K hours, no driver |
Designed For | Industrial |
Frame Rate | 60Hz |
Screen weight | 157g (Typ.) |
Touch Panel | Without |
Interface Type | 50 pins Parallel RGB (1 ch, 6/8-bit), Connector |
Power Supply | 3.3V (Typ.) |
Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
G070VVN01.0 7 inch 800*480 Suitable for industrial displays |
G070VVN01.0 Contact Us:
1. If there's any problem, please do not hesitate to contact us by message, we will reply you within 1 business day. (Not include public holiday)
2. Working Hours: Monday to Saturday
3. If you don't get response within 1-2 business days, please check your email or My Messages in case your email provider has an overly aggressive spam filter blocking or my emails. Please add us in your contact and email us again.
4. Bulk order is acceptable, lower prices will be offered to you for bulk order.
G070VVN01.0 Our service:
> Fast delivery
> 90days warranty
> original,High quality
> Full tested before shipping.
G070VVN01.0 Payment:
1. We accept Escrow, Alipay, Paypal, T/T(Bank Transfer), Credit Card, Western Union, Moneygram, etc....
2. If you have any problems of payment, please contact us.
G070VVN01.0 SHIPPING:
1 We will ship the items within 3working days after the payment is reached.
2 We often ship to customers by UPS/DHL/Fedex and ect,We would like to ship to you which is convenient to you. Please contact us directly and we will use your preferred ways.
3 We are not responsible for any accidents, delays or other issues that we couldn’t control, But we will contact the shipping company which is our long term cooperation.
4 Any import fees or charges are the buy’s responsibility.
G070VVN01.0 Refund&Return:
1. If the item is defective, pls notify us within 3 days after receiving.
2. items should be returned with original package if possible.
G070VVN01.0 FAQ:
Q: When would you ship,IF I order G070VVN01.0?
A: The order are shipped within 1-2 working days after received the payment.
Q: How to order AUO G070VVN01.0 ?
A: We accept T/T , PAYPAL , WESTERN UNION.
Q: Can you test 7.0 inch lcd panel G070VVN01.0 before shipping?
A: Don't Worry , The G070VVN01.0 will be tested ok before shipping
Q: What happen if AUO G070VVN01.0 received can't work ?
A: Our AUO G070VVN01.0 was tested ok before shipping .If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
G070VVN01.0 Shippment & Packing
