AA192AA01 Mitsubishi 19.2 inch 1920×360 TFT LCD Screen Display for Industrial use
Product Details:
| Place of Origin: | China |
| Brand Name: | Mitsubishi |
| Model Number: | AA192AA01 |
| Document: | AA192AA01.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | AA192AA01 | Panel Size: | 19.2" (Native Bar) |
|---|---|---|---|
| Resolution: | 1920(RGB)×360, 102PPI | Display Area: | 478.08(W)×89.64(H) Mm |
| Bezel Opening: | 481.1(W)×92.0(H) Mm | Outline Size: | 496(W)×109.2(H)×13.9(D) Mm |
| Weight: | 780g (Typ.) | Application: | Industrial / Stretched Bar LCD |
Product Description
AA192AA01 Mitsubishi 19.2 inch 1920×360 TFT LCD Screen Display for Industrial use
AA192AA01 Product details :
| Mitsubishi LCD SCREEN AA192AA01 | |
| Manufacturer | Mitsubishi |
| Model Name | AA192AA01 |
| Screen Size | 19.2 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×360 102PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 478.08 × 89.64 (H×V) |
| Outline(mm) | 496 × 109.2 × 13.9 (H×V×D) |
| Bezel Area(mm) | 481.1 × 92.0 (H×V) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 700 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) |
| Response | 4/12 (Typ.)(Tr/Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 262K/16.7M 50% NTSC |
| Backlight | WLED , 100K hours , With LED Driver |
| Mass | 780g (Typ.) |
| Used for | Industrial / Stretched Bar LCD |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
| AA192AA01 Mitsubishi 19.2 inch 1920×360 TFT LCD Screen Display for Industrial use | |
AA192AA01 Our services:
Accepted Delivery Terms: FOB,CIF, EXW, Express Delivery；
Accepted Payment Currency: USD, CNY;
Accepted Payment Type: T/T, PayPal, Escrow;
Language Spoken:English,Chinese.
AA192AA01 Shippment & Packing
AA192AA01 lead time:
Mass order: 7--15days depending on order quantity.
Sample: 1day when there is stock,3-7days for custom design.
AA192AA01 Packing:
Standard export package: Bubble bag+hard paper carton
AA192AA01 Delivery:
3 days after the payment.The transport mode base on customer's requirment
AA192AA01 About warranty and Return:
We offer one year warranty for most of our products and professional technical support .
Please contact us if there are any problems and we will do my best to fix it out. Here is our misrepresented & unsatisfied merchandise policy.
-- 1. We accept returns for replacement or refund within 5 days after receipt of item(s). Items MUST be in their original condition, not worn or altered.
-- 2. We do not reimburse the return shipping charge. Refunds will be for the original price paid, and will be issued within 7 business days after receipt of the return.
AA192AA01 FAQ:
Q: Do you accept the sample order of Mitsubishi lcd display AA192AA01 ?
A: Yes, Welcome !
Q: What happen if the Mitsubishi lcd AA192AA01 I received can't work ?
A: our lcd screen AA192AA01 was tested ok before shipping .If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
Q: How long the warranty of TFT-LCD AA192AA01 ?
A: 90days .
Q: Can you declared low price of my order Mitsubishi AA192AA01 ?
A: 90 days .
