INNOLUX G121ICE-L02 12.1 inch lcd screen new module with 1280×800 WXGA 124PPI for industrial use
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | G121ICE-L02 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | G121ICE-L02 | Diagonal Size: | 12.1 Inch |
|---|---|---|---|
| Pixel Format: | 1280(RGB)×800 [WXGA] 124PPI | Active Area: | 261.12(H)×163.2(V) Mm |
| Outline Dim.: | 278(H)×184(V)×11(D) Mm | Bezel Area: | 264.12(H)×166.2(V) Mm |
| Weight: | 470/490g (Typ./Max.) | Designed For: | Industrial |
Product Description
INNOLUX G121ICE-L02 12.1 inch lcd screen new module with 1280×800 WXGA 124PPI for industrial use
G121ICE-L02 Product details :
| Innolux LCD SCREEN G121ICE-L02 | |
| Manufacturer | Innolux |
| Model Name | G121ICE-L02 |
| Screen Size | 12.1 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1280(RGB)×800 (WXGA) 124PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 261.12 × 163.2 (H×V) |
| Outline(mm) | 278 × 184 × 11 (H×V×D) |
| Bezel Area(mm) | 264.12 × 166.2 (H×V) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Min.) (TM) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Response | 12/8 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | AAS, Normally Black, Transmissive |
| Color Depth | 262K/16.7M 72% NTSC |
| Backlight | WLED , 50K hours , With LED Driver |
| Mass | 470/490g (Typ./Max.) |
| Used for | Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 70 °C |
| INNOLUX G121ICE-L02 12.1 inch lcd screen new module with 1280×800 WXGA 124PPI for industrial use | |
G121ICE-L02 Our service:
Accepted Delivery Terms: FOB,CIF,CIP；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CHF;
Accepted Payment Type: T/T,L/C,MoneyGram,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,German,Russian
G121ICE-L02 HIGHEST QUALITY STANDARD DISPLAYS:
As a distributor,YONGS display provides technical support for the development of every type and class of LCD, from the design stage right through to the production phase, while guaranteeing the highest quality standards.
Our products can be customized for various applications and market sectors, including (but not limited to): automotive, medical, building automation, white goods, digital signage, security, transportation and industrial.
G121ICE-L02 Shippment & Packing
G121ICE-L02 About Shipping:
1, Pls make sure the lcd model you need is the exact model you ordered. We shipping according to the ordered model.
2, Pls make sure the address is correct. We will ship to the address in the order. lf you need to ship to different place, pls email us the address right after you made the payment.
3, Shipment will be made within 3 business days after the payment received.
4, We will test each panel strictly before shipping and make very good package of it.
G121ICE-L02 FAQ:
Q: Can you declared low value for my order G121ICE-L02 when shipping?
A: Yes, We can do it for you if you need.
Q: How to order if I don't know the lcd panel number ?
A: You can offer 2-3 photos (back-side and front-side) for your lcd panel ,So that we can check the panel to you.
Q: What is the different between original lcd panel and compatible lcd display?
A: Function is the same , Of course the original lcd's quality and lifetime better than that compatible lcd .
Q: What happen if the lcd panel G121ICE-L02 I received can't work ?
A: Innolux G121ICE-L02 was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
