PV156FHM-T00 Brand New BOE 15.6 inch Panel 1920*1080 TFT Display Full View for Industrial
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | PV156FHM-T00 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | PV156FHM-T00 (BOE083E) | Diagonal Size: | 15.6 Inch |
|---|---|---|---|
| Pixel Format: | 1920(RGB)×1080 [FHD] 141PPI | Active Area: | 344.16(H)×193.59(V) Mm |
| Outline Dim.: | 361(H)×223(V)mm | Weight: | 670g (Max.) |
| Designed For: | Industrial | Touch Panel: | On-Cell Touch |
Product Description
PV156FHM-T00 Brand New BOE 15.6 inch Panel 1920*1080 TFT Display Full View for Industrial
PV156FHM-T00 (BOE083E) Product details :
| BOE LCD SCREEN PV156FHM-T00 (BOE083E) | |
| manufacturer | BOE |
| Model Name | PV156FHM-T00 (BOE083E) |
| screen size | 15.6 inch |
| Screen type | Assembly, a-Si TFT-LCD |
| Resolution | 1920(RGB)×1080 (FHD) 141PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 344.16 × 193.59 (H×V) |
| physical dimension | 361 × 223 (H×V×D) |
| surface treatment | Antiglare, Hard coating (3H) |
| Brightness | 400 cd/m² (Min.) |
| Contrast | 800 : 1 (Typ.) (TM) |
| Best angle | Symmetry |
| Optical mode | ADS, Normally Black, Transmissive |
| Viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| Responding time | 30 (Typ.)(Tr+Td) ms |
| Number of color | 16.7M 45% NTSC |
| Backlight type | 16.7M 45% NTSC |
| Panel weight | 670g (Max.) |
| Apply to | Industrial |
| Refresh rate | 60Hz |
| Touch function | On-Cell Touch |
| signal system | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , Connector 40 pins |
| Supply voltage | 3.3V (Typ.) |
| Maximum rating | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| 15.6 inch FHD PV156FHM-T00 TFT LCD Panel Screen Display Touch Digitizer | |
PV156FHM-T00 (BOE083E) Our Services:
Payment:T/T, Bank transfer ,western union , Others can be in consideration.
Packing:Bubble bag+Bubble chamber+Suitable hard carton
After-sales service:If you have any problem about product, please feel free to contact us. We will reply you within 12 hours.
Warranty: Usually, product warranty for 180days.
MOQ:1 piece or Sample order will be available.
Advantages:Best Price, High Quality, Fast Delivery, Good Service, Responsible Salesperson.
Samples: Our company offers samples for quality test or other business purposes, but we kindly ask you to pay for samples and the freight.
Quality:100% Grade A tested before shipping
PV156FHM-T00 (BOE083E) Shippment & Packing
PV156FHM-T00 (BOE083E) SHIPPING:
3-15 working days since payment confirmed (based on actual quantity)
Tracking Number will be sent after delivery .And you will get every importantshipping status by email.
PV156FHM-T00 (BOE083E) FAQ:
Q: Can you give me a discount if I need a large quantity of PV156FHM-T00 (BOE083E) ?
A: Of course!If you make a large order, we will give you a discount.
Q: How long will I receive my goods of PV156FHM-T00 (BOE083E) ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment for PV156FHM-T00 (BOE083E) ?
A: We accept T/T , Paypal , western union .
Q: Can You declare my order of lcd display screen PV156FHM-T00 (BOE083E) at a very low value ?
A: Yes , we can . pls inform us before shipping .
