N156HRA-EA1 15.6 Inch Laptop Screen EDP 40 Pin IPS FHD 1920x1080
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | N156HRA-EA1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | N156HRA-EA1 | Screen Size: | 15.6 Inch |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080 (FHD) 141PPI | Active Area(mm): | 344.16 × 193.59 (H×V) |
| Outline(mm): | 350.66 × 216.25 × 3.2 (H×V×D) | Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) |
| Color Depth: | 16.7M 45% NTSC | Designed For: | Laptop Gaming |
| High Light: | N156HRA-EA1 15.6 Inch Laptop Screen,IPS FHD 15.6 Inch Laptop Screen |
||
Product Description
N156HRA-EA1 EDP 40 Pin IPS FHD 1920x1080 15.6 Inch Laptop Screen
N156HRA-EA1 Product details :
1: Products: We have all the spare parts and accessories for all the models of mobile phones,laptops, and tablet PC
2 : Price can be negotiable based on quantity; delivery terms;
3 : Samples: We can offer samples ,but we kindly ask you pay for samples and the freight.
4: Quality guarantee: We will inspect the appearance and test functions of all of our items before shipping, so it is very important for our customers to let professional operators test and install them.
5: Package: All the items will be packed very well to avoid damage.
6: After-service: We provide best after-service, any problem will be solved successfully and smoothly, 100% satisfaction guaranteed.
| Innolux LCD SCREEN N156HRA-EA1 | |
| Manufacturer | Innolux |
| Model Name | N156HRA-EA1 |
| Screen Size | 15.6 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 141PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 344.16 × 193.59 (H×V) |
| Outline(mm) | 350.66 × 216.25 × 3.2 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 11/9 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | AAS, Normally Black, Transmissive |
| Color Depth | 16.7M 45% NTSC |
| Backlight | WLED , 15K hours , With LED Driver |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Used for | Laptop Gaming |
| Refresh Rate | 144Hz |
| Touchscreen | Without |
| Signal Type | eDP (4 Lanes) , eDP1.3 , Connector 40 pins |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| N156HRA-EA1 EDP 40 Pin IPS FHD 1920x1080 15.6 Inch Laptop Screen | |
N156HRA-EA1 Our Services:
1. Reply emails within 24 hours.
2. Good service after sold.
3. Fast shipping, goods to be sent out within 3 working days after payment.
4. Check one by one to make sure each one is A grade, without scratches or other problems.
5. Testing before shipment.
N156HRA-EA1 Payment:
We can accept T/T and Western Union and Money order, the best way is direct order payment .you can choose your convenient payment terms. If you want other payment terms, please let us know before you order.
Full payment must be made within 7 days after placing your order, or the order will be invalid or cancelled by the system.
Make sure that you have completed all the detailed information like contact person, address, post code and telephone number when filling in your buyer’s information.
N156HRA-EA1 PACKAGE:
Standard export carton packing.
N156HRA-EA1 DELIVERY TIME:
3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
N156HRA-EA1 Return & Replacement/Exchange policy:
1.If you have found any problems about our item after you tested it , pls contact us and we will reply ASAP.
2.Items can be returned for exchange within 10 days counting from the day you receive merchandise. Goods must be unworn and in original packaging.
3.Items returned will be tested by our technician, if it is true,we will refund or replace the defective merchandise,if not, the return policy will be unavailable for the buyer.
N156HRA-EA1 FAQ:
Q: Can I pay my goods N156HRA-EA1 by credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can you give me a discount if I need a large quantity of N156HRA-EA1 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Do you accept sample orders for N156HRA-EA1 ?
A: Of course!sample order is welcome !
Q: How to make payment for N156HRA-EA1 ?
A: We accept T/T , Paypal , western union .
N156HRA-EA1 Shippment & Packing
