NE156QUM-N63 LCD Laptop Screen EDP 40 Pin 15.6 Inch UHD 3840x2160
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | NE156QUM-N63 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | NE156QUM-N63 (BOE07F4 BOE0769) | Diagonal Size: | 15.6 Inch |
|---|---|---|---|
| Pixel Format: | 3840(RGB)×2160 [UHD] 283PPI | Active Area: | 344.218(H)×193.622(V) Mm |
| Outline Dim.: | 350.66(H)×216.45(V)×2.6(D) Mm | Operating Mode: | ADS, Normally Black, Transmissive |
| Form Style: | Slim (PCBA Flat, T≤3.2mm) | Designed For: | Laptop |
| High Light: | NE156QUM-N63 LCD Laptop Screen,Symmetry LCD Laptop Screen |
||
Product Description
NE156QUM-N63 Laptop Screen eDP 40 pin 15.6 inch UHD LED 3840*2160 IPS laptop
NE156QUM-N63 Product details :
| BOE LCD SCREEN NE156QUM-N63 | |
| Manufacturer | BOE |
| Model Name | NE156QUM-N63 |
| Screen Size | 15.6 inch |
| Screen Type | LCM , Oxide TFT-LCD |
| Pixel Number | 3840(RGB)×2160 (UHD) 283PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 344.218 × 193.622 (H×V) |
| Outline(mm) | 350.66 × 216.45 × 2.6 (H×V×D) |
| Treatment | Antiglare |
| Luminance | 340 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 25(Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 16.7M 72% NTSC |
| Backlight | 10S5P WLED , 15K hours , With LED Driver |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | eDP (4 Lanes) , eDP1.4a , HBR2 (5.4G/lane) , 40 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| NE156QUM-N63 Laptop Screen eDP 40 pin 15.6 inch UHD LED 3840*2160 IPS laptop | |
NE156QUM-N63 Our service:
1. We ship within 2~5 days as soon as possible；
2. We support sample service, MOQ = 1；
3. We have strong R & D and production capabilities and have sufficient inventory；
4. We will innovate and develop new products every month；
5. We are OEM / ODM；
6. We are at your service 24 hours. Product quality issues can be returned at any time；
7. We ship your products with the fastest and best logistics；
NE156QUM-N63 Payment:
Payment term: T/T before shipment.
We accept payment via the Paypal /Western union/TT, you can choose as you like.
NE156QUM-N63 Shippment & Packing
NE156QUM-N63 About signing for the package:
each of our packages is packed in a reliable and firm way, but sometimes the courier company sends the package rudely, which will cause the components to be lost or damaged. The loss caused by this can be claimed by the courier company for compensation. If you find that the package is damaged and the electronic components are exposed when you sign for it, before unpacking, you need to pick up your mobile phone and record a video about you opening the package, which will be beneficial evidence for disputes on the platform. When inspecting the goods, please check whether the purchased model and quantity are wrong and whether the packaging is damaged. If there is any problem,please contact us in time.
NE156QUM-N63 Warranty:
1.Our side always double check all the products before delivery to make sure correct.
2.All components we sell has 30 days return policy from the day of shipment, but if the damag e is man-made, we will be unable to change for you.
NE156QUM-N63 FAQ:
Q: Can you give me a discount if I need a large quantity of NE156QUM-N63?
A: Of course!If you make a large order, we will give you a discount.
Q: If I place order now,when will you ship the goods of NE156QUM-N63?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can You declare my order of NE156QUM-N63 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How can I trace my order of NE156QUM-N63 ?
A: we will give you tracking number then you can trace your order from website.
