15.6 Inch TFT LCD Screen RGB 1920X1080 NL192108AC18-02D For NLT
Product Details:
| Place of Origin: | China |
| Brand Name: | NEC |
| Model Number: | NL192108AC18-02D |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | NL192108AC18-02D | Panel Size: | 15.6" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD, 141PPI | Display Area: | 344.16(W)×193.59(H) Mm |
| Bezel Opening: | 347.55(W)×196.75(H) Mm | Outline Size: | 363.8(W)×215.9(H)mm |
| Panel Weight: | 610/670g (Typ./Max.) | Application: | Industrial |
| High Light: | NL192108AC18-02D tft lcd screen,NLT tft lcd screen |
||
Product Description
15.6 inch 1920(RGB)×1080 NL192108AC18-02D tft screen lcd display for NLT
NL192108AC18-02D Product details :
| NLT LCD SCREEN NL192108AC18-02D | |
| manufacturer | NLT |
| Model Name | NL192108AC18-02D |
| screen size | 15.6 inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 1920(RGB)×1080 (FHD) 141PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 344.16 × 193.59 (H×V) |
| physical dimension | 363.8 × 215.9 (H×V×D) |
| Visual size | 347.55 × 196.75 (H×V) |
| surface treatment | Antiglare, Hard coating (3H) |
| Brightness | 400 cd/m² (Typ.) |
| Contrast | 1000 : 1 (Typ.) (TM) |
| Best angle | Symmetry |
| Optical mode | UA-SFT, Normally Black, Transmissive |
| Viewing angle | 88/88/88/88 (Typ.)(CR≥10) |
| Responding time | 12/13 (Typ.)(Tr/Td) ms |
| Number of color | 16.7M 72% NTSC |
| Backlight type | WLED , 50K hours , With LED Driver |
| Panel weight | 610/670g (Typ./Max.) |
| Apply to | Industrial |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Supply voltage | 3.3V (Typ.) |
| Maximum rating | Storage Temp.: -30 ~ 80 °C ,Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| 15.6 inch 1920(RGB)×1080 NL192108AC18-02D tft screen lcd display for NLT | |
NL192108AC18-02D Product Paramenters:
* every item is as the picture showed and the title description.
* if you have any problem with the item, please contact me before you buy it, we will reply to you as soon as possible
* Each item has been checked and in good condition before shipping.
* It is shipped in protective bubble wrap and has all the protective screen coatings, so, please do not worry.
* if the item has some problem, please contact us at first time. I will help you solve problems and try our best to make you be satisified.
* happy do business with you, i think communication will solve all the problem .so, please do not be hesitate to contact us.
Why choose us NL192108AC18-02D ?
1.High quality,aff of items will be tested ok before ship out.
2.Best price,have a big inventory,so our price is more advantageous than other companies.
3.Fast delivery,ship within 24 hours.4.Small order accepted,MOQ 1PcS.
NL192108AC18-02D Shipping and Package :
NL192108AC18-02D Shipping :
1. We will ship the items within 3 working days after the payment is reached.
2. All the goods will be tested before shipment.
3. Packing in professional anti-static bag.
4. We can ship to you by DHL/TNT/UPS/EMS/Fedex/Post..
NL192108AC18-02D Guarantee:
1. All LCD panels will be tested good before shipping.
2. Warranty period: 3 months
NL192108AC18-02D Return & Replace:
1. If the products you received are Non-artificial damaged, please notify us in 3 days.
2. Products should be returned with original package and be in good condition if possible.
3. Customers need to bear the freight of returned product.
NL192108AC18-02D FAQ:
Q: How long is the warranty of NL192108AC18-02D ?
A: 90days warranty .
Q: Can you give me a discount if I need a large quantity of NL192108AC18-02D ?
A: Of course!If you make a large order, we will give you a discount.
Q: How can I trace my order of NL192108AC18-02D ?
A: we will give you tracking number then you can trace your order from website.
Q: If I order NL192108AC18-02D now,when will you ship the goods ?
A: The order will be shipped within 2-3 working days after received your payment.
