5.7 Inch LCD Screen Display Panel NL6448BC18-03F For Industrial Equipment
Product Details:
| Place of Origin: | China |
| Brand Name: | NEC |
| Model Number: | NL6448BC18-03F |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | NL6448BC18-03F | Screen Size: | 5.7 Inch |
|---|---|---|---|
| Pixel Number: | 640(RGB)×480 (VGA) 139PPI | Active Area(mm): | 116.16 × 87.12 (H×V) |
| Outline(mm): | 135 × 104.6 × 10.9 (H×V×D) | Bezel Area(mm): | 120.2 × 91.2 (H×V) |
| Mass: | 165/175g (Typ./Max.) | Used For: | Industrial |
| Highlight: | 5.7 Inch LCD Screen Display Panel,LCD Screen Display Panel NL6448BC18-03F |
||
Product Description
New Original 5.7 inch NL6448BC18-03F LCD Screen Display Panel for Industrial Equipment
NL6448BC18-03F Product details :
| NEC LCD Screen NL6448BC18-03F | |
| Manufacturer | NEC |
| Model Name | NL6448BC18-03F |
| Screen Size | 5.7 inch |
| Screen type | a-Si TFT-LCD, LCM |
| Number of pixels | 640(RGB)×480, VGA, 139PPI |
| Pixel layout | RGB vertical bar |
| Display area | 116.16(W)×87.12(H) mm |
| Viewable area | 120.2(W)×91.2(H) mm |
| physical dimension | 135(width)×104.6(height) ×10.9(thickness) mm |
| Surface treatment | Clear, Hard coating (3H) |
| Panel brightness | 800 cd/m² (Typ.) |
| Contrast | 850:1 (Typ.) (TM) |
| Viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| Operating mode | TN, normally white display, transmissive |
| Best perspective | 9 o'clock |
| Reaction time | 3/15 (Typ.)(Tr/Td) |
| Display color | 262K, 60% NTSC |
| type of light source | 9S2P×2CN WLED, 50K hours, without driver |
| working frequency | 60Hz |
| touch screen | No touch |
| Panel weight | 165/175g (Typ./Max.) |
| Signal interface | CMOS (1 ch, 6-bit), 33 pins, connector |
| Drive screen voltage | 3.3V (Typ.) |
| working environment | Work: -30 ~ 80 °C; Storage: -30 ~ 80 °C; Vibration resistance: 2.0G (19.6 m/s²) |
| New Original 5.7 inch NL6448BC18-03F LCD Screen Display Panel for Industrial Equipment | |
NL6448BC18-03F Payment:
1.Generally, we accept the following payment methods: credit card;moneybookers;T/T;western union.
NL6448BC18-03F Shipping and Package :
NL6448BC18-03F Packing :
Outer packing is strong carton , inner packing is foam , it will be strong and safe enough , to avoid getting broken in the transport .
NL6448BC18-03F Shipment:
1. We will sent the items within 2-5days (working days, Not holiday seasons)after the payment being confirmed by the platform.
2.The shipment by China Post Registered Air Mail for less than 2kg goods in 15-25 working days, If you need the item urgently, please contact us for express shipping.
We will calculate the express shipping cost for you.
3.When you receive the items you ordered, in 24 hours, please check it carefully.Please contact us directly if you have any problems.
4.If you have not got it within the shipping time,please contact us without hesitation.We will check it for you with the post office and customs.
NL6448BC18-03F Warranty and Return:
1. We offer warranty for all of our products.
2. Buyers bear the shipping cost for returning defective or non-defective item to us.
3. Return items should be in good condition same as we sent, not damaged.
4. Returned items are subject to approval by us, it should be in original box as we sent.
5. Physically damaged items received should be reported within 2 days.
6. All NON-Seller Mistake returns, there is 15% re-stocking fees and shipping and handling charges are NON-refundable. (E.g. you boughtwrong item)
NL6448BC18-03F FAQ:
Q: Can You declare my order of NL6448BC18-03F to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How to make payment of NL6448BC18-03F ?
A: We accept T/T , Paypal , western union .
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: How long will I receive my goods NL6448BC18-03F ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
