M315DJJ-K31 TFT LCD Screen Module 32.0 Inch 3840X2160 TFT LCD Display Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | M315DJJ-K31 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | M315DJJ-K31 | Diagonal Size: | 32.0 Inch |
|---|---|---|---|
| Pixel Format: | 3840(RGB)×2160 (UHD) 139PPI | Active Area: | 698.4 × 392.85 (H×V) |
| Outline Dim.: | 717.4 × 413.85 × 18.9 (H×V×D) | Bezel Area: | 703.4 × 397.85 (H×V) |
| Color Depth: | 1.07B 98% DCI-P3 | Designed For: | Desktop Monitor Industrial Gaming |
| High Light: | M315DJJ-K31 tft lcd screen module,32.0 Inch tft lcd screen module,Symmetry tft lcd display panel |
||
Product Description
M315DJJ-K31 32.0 inch 3840*2160 tft screen lcd display tft lcd screen module tft lcd display panel
M315DJJ-K31 Product details :
| Innolux LCD SCREEN M315DJJ-K31 | |
| Manufacturer | Innolux |
| Model Name | M315DJJ-K31 |
| Screen Size | 32.0 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 3840(RGB)×2160 (UHD) 139PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 698.4 × 392.85 (H×V) |
| Outline(mm) | 717.4 × 413.85 × 18.9 (H×V×D) |
| Bezel Area(mm) | 703.4 × 397.85 (H×V) |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 400 (Typ.)(cd/m²) |
| Contrast Ratio | 3000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 15/5 (Typ.)(Tr/Td); 9.5 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | MVA, Normally Black, Transmissive |
| Color Depth | 1.07B 98% DCI-P3 |
| Backlight | WLED , 30K hours , No Driver |
| Mass | 3.46±0.18Kgs |
| Used for | Desktop Monitor Industrial Gaming |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | V-by-One 8 lane , 51 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| M315DJJ-K31 32.0 inch 3840*2160 tft screen lcd display tft lcd screen module tft lcd display panel | |
Welcome to YONGS
- We have the supply of technology, can provide you with technical advide.Please send your RFQ(request for quoting) to get latest price.
- We provide a wide variety of LCD screens, touch screens, inverters and other accessories.
- Many of the original LCD screen has been discontinued, we sell the Used ones of great working condition. If you need more than 10 pcs, please contact us for a good discount.
- If you are not sure whether the product is the one you need or if you need more, please contact me before ordering.We have the supply of technology, can provide you with technical adviPlease send your RFQ(request for quoting) to get latest price.
M315DJJ-K31 Shipment:
1.We will sent the items within 2-5days (working days, Not holidayseasons)after the payment being confirmed by the platform.
2.The shipment by China Post Registered Air Mail for less than 2kggoods in 15-25 working days, If you need the item urgently, pleasecontact us for express shipping.
We will calculate the express shipping cost for you.
3. When you receive the items you ordered, in 24 hours, please checkit carefully.Please contact us directly if you have any problems.
4.If you have not got it within the shipping time,please contact uswithout hesitation. We will check it for you with the post office andcustoms.
M315DJJ-K31 About item and shipping price:
1. For products that are rarely sold or never sold, the item price may not be accurate, please contact me for the correct quote.
2. For remote countries or islands, prices may be inaccurate, high or low, please contact me for the correct quote.
M315DJJ-K31 Guarantee:
1. 12 months Manufacturer`s limited Warranty for defective items (excluding items damaged and/or misused after receipt). Accessories come with a 3-month warranty.
2. Defective items MUST BE reported and returned within the warranty period (and in the original packaging, if possible). You must tell us what the defect is and give us your order number. WE DO NOT REPAIR OR REPLACE ITEMS WITH AN EXPIRED WARRANTY.
You agree to all of the above-listed policies upon ordering !
M315DJJ-K31 FAQ:
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Do you accept sample orders of M315DJJ-K31 ?
A: Of course!sample order is welcome !
Q: How to make payment of M315DJJ-K31 ?
A: We accept T/T , Paypal , western union .
Q: Can I pay my order of M315DJJ-K31 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
M315DJJ-K31 Shipping and Package :
