M236HJJ-P02 Rev.C1 Laptop Screen 23..6 Inch Led 1920*1080 30 pins Connector
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | M236HJJ-P02 Rev.C1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | M236HJJ-P02 Rev.C1 | Panel Size: | 23.6 Inch |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080 (FHD) 93PPI | Display Area: | 521.28 × 293.22 (H×V) |
| Outline Size: | 534.28 × 306.252 (H×V×D) | Contrast Ratio: | 3000 : 1 (Typ.) (TM) |
| Color Depth: | 16.7M 72% NTSC | Application: | Desktop Monitor |
Product Description
M236HJJ-P02 Rev.C1 Laptop Screen 23.6 Inch Led 1920*1080 30 pins Connector
M236HJJ-P02 Rev.C1 Product details :
| Innolux LCD SCREEN M236HJJ-P02 Rev.C1 | |
| Manufacturer | Innolux |
| Model Name | M236HJJ-P02 Rev.C1 |
| Screen Size | 23.6 inch |
| Screen Type | CELL , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 93PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 521.28 × 293.22 (H×V) |
| Outline(mm) | 534.28 × 306.252 (H×V×D) |
| Treatment | Antiglare (Haze 3%), Hard coating (3H) |
| Luminance | 0cd/m² (Typ.) |
| Contrast Ratio | 3000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 10 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | Super MVA, Normally Black, Transmissive |
| Color Depth | 16.7M 72% NTSC |
| Backlight | No B/L |
| Mass | TBD |
| Used for | Desktop Monitor |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| D-IC Detail | COF Built-in 6 source chips |
| Signal Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| M236HJJ-P02 Rev.C1 Laptop Screen 23.6 Inch Led 1920*1080 30 pins Connector | |
M236HJJ-P02 Rev.C1 Helpful Information:
To make sure you purchase a correct screen, please be sure to match size, resolution, and backlight of product. If you are uncertain, please contact us with your lcd brand/serial/model, or model number on back of the screen. Our technicians will help you to choose the correct screen.
M236HJJ-P02 Rev.C1 Packing :
Outer packing is strong carton , inner packing is foam , it will be strong and safe enough , to avoid getting broken in the transport .
M236HJJ-P02 Rev.C1 Please Noted
we are not responsible for any customsduty or import tax .
M236HJJ-P02 Rev.C1 Shipping :
1. Standard transportation and distribution by express line.
2, We will send out your goods within 3 working days after we get your order .
3, Normally , you can get the goods within 10-20 calendar days .
4, Please make sure your shipping information ( including address / post code / phone number / contact person ) are correct before order . If you want us send it to another address , pls inform us in advance , and leave message in our transaction.
M236HJJ-P02 Rev.C1 Noted:
If you want any help you can contact with your customer service or give us your email box,we will reply you within 12 hours
All products will be tested before shipping
For all order must return to us if any reason you don't like it ,you can order it then you accept the rule, we paid the shipping cost
from china, the buyer must pay the return cost by EMS only,please don't order if you don't accept
M236HJJ-P02 Rev.C1 FAQ:
Q: How long will I receive my goods M236HJJ-P02 Rev.C1 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can you give me a discount if I need a large quantity of M236HJJ-P02 Rev.C1 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of M236HJJ-P02 Rev.C1 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How long is the warranty ?
A: We offer 90days warranty .
M236HJJ-P02 Rev.C1 Shipping and Package :
