LS315M7LX01 32.0 inch 1920*1080 TFT LCD Screen LCD Displays
Product Details:
| Place of Origin: | China |
| Brand Name: | Sharp |
| Model Number: | LS315M7LX01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LS315M7LX01 | Screen Size: | 32.0" |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080, FHD 69PPI | Active Area(mm): | 696.96(W)×392.04(H) Mm |
| Outline(mm): | 734(H)×420(V)×17.7(D)mm | Contrast Ratio: | 15:1 (Typ.) (RF) |
| Support Color: | 16.7M 15%NTSC | Used For: | Industrial、Digital Signage |
| Light Source: | WLED, 50K Hours, W/O Driver | Frame Rate: | 60Hz |
Product Description
LS315M7LX01 32.0 inch 1920*1080 TFT LCD Screen LCD Displays
LS315M7LX01 Product details :
| Brand | Sharp |
| Model P/N | LS315M7LX01 |
| Diagonal Size | 32.0" |
| Panel Type | Oxide TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD 69PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 696.96(W)×392.04(H) mm |
| Bezel Opening | 699(W)×394(H) mm |
| Outline Dim. | 734(H)×420(V)×17.7(D)mm |
| Treatment | Clear, Hard coating |
| Luminance | 25 cd/m² (Typ.) |
| Contrast Ratio | 15:1 (Typ.) (RF) |
| View Direction | Symmetry |
| Response Time | 20 (Typ.)(Tr+Td) |
| Viewing Angle | 60/60/60/60 (Typ.)(CR≥2) |
| Operating Mode | Normally Black, Transflective |
| Support Color | 16.7M 15%NTSC |
| Light Source | WLED, 50K hours, W/O Driver |
| Weight | 5.00 Kgs |
| Designed For | Industrial,Digital Signage |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (2 ch, 8-bit), 51 pinsConnector |
| Power Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -20 ~ 70 °C |
| TFT LCD Screen LS315M7LX01 Original 32.0 inch LCD Display Panel | |
