M215HJJ-L30 Rev.C5 1920*1080 Resolution ips screen 21.5 inch TFT LCD lcd display for touch screen display kiosk
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | M215HJJ-L30 Rev.C5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | M215HJJ-L30 Rev.C5 | Screen Size: | 21.5 Inch |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080 (FHD) 102PPI | Active Area(mm): | 476.064 × 267.786 (H×V) |
| Outline(mm): | 495.6 × 292.2 × 11.5 (H×V×D) | Color Depth: | 16.7M 72% NTSC |
| Mass: | 1.80/1.89Kgs (Typ./Max.) | Used For: | Desktop Monitor Industrial |
Product Description
M215HJJ-L30 Rev.C5 1920*1080 Resolution ips screen 21.5 inch TFT LCD lcd display
M215HJJ-L30 Rev.C5 Product de tails :
| Innolux LCD SCREEN M215HJJ-L30 Rev.C5 | |
| Manufacturer | Innolux |
| Model Name | M215HJJ-L30 Rev.C5 |
| Screen Size | 21.5 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 102PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 476.064 × 267.786 (H×V) |
| Outline(mm) | 495.6 × 292.2 × 11.5 (H×V×D) |
| Bezel Area(mm) | 479.84 × 271.3 (H×V) |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 250cd/m² (Typ.) |
| Contrast Ratio | 3000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 20/5 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | MVA, Normally Black, Transmissive |
| Color Depth | 16.7M 72% NTSC |
| Backlight | 4 strings WLED , 40K hours , No Driver |
| Mass | 1.80/1.89Kgs (Typ./Max.) |
| Used for | Desktop Monitor Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| M215HJJ-L30 Rev.C5 1920*1080 Resolution ips screen 21.5 inch TFT LCD lcd display for touch screen display kiosk | |
