M195FGE-L20 19.15inch laptop screen monitor for display replacement
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | M195FGE-L20 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | M195FGE-L20 | Screen Size: | 19.5 Inch |
|---|---|---|---|
| Pixel Number: | 1600(RGB)×900 (HD+) 94PPI | Active Area(mm): | 432 × 239.76 (H×V) |
| Outline(mm): | 452 × 263 × 11 (H×V×D) | Bezel Area(mm): | 435.3 × 243.06 (H×V) |
| Mass: | 1.43/1.50Kgs (Typ./Max.) | Used For: | Desktop Monitor |
Product Description
M195FGE-L20 19.15inch laptop screen monitor for display replacement
Product details :
| Innolux LCD SCREEN M195FGE-L20 | |
| Manufacturer | Innolux |
| Model Name | M195FGE-L20 |
| Screen Size | 19.5 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1600(RGB)×900 (HD+) 94PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 432 × 239.76 (H×V) |
| Outline(mm) | 452 × 263 × 11 (H×V×D) |
| Bezel Area(mm) | 435.3 × 243.06 (H×V) |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Response | 5 (Typ.)(Tr+Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 16.7M 72% NTSC |
| Backlight | WLED [10S4P] , 40K hours , W/O Driver |
| Mass | 1.43/1.50Kgs (Typ./Max.) |
| Used for | Desktop Monitor |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| M195FGE-L20 19.15inch laptop screen monitor for display replacement | |
We Promise to:
1:Only sell the best consumer goods and ensure the highest quality possible.
2:Deliver goods to our customers all over the world with speed and precision
Customer Service Policy:
We are more than happy to answer any questions that you have, please contact with
1:Orders processed timely after the payment verification.
2:We only ship to confirmed order addresses. Your order address MUST MATCH your Shipping address.
3:If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction!
4:Due to stock status and time differences, we will choose to ship your item from our first available warehouse for fast delivery.
M195FGE-L20 Shipping details:
1.We will test them strictly before shipping.
2.We will ship it within 3 working days after we get the order.
3.The delivery time normally will be 7 to 50 days, which will be different for different countries. You can choose AliExpress Standard Shipping,It is faster than others.
4.* United States / United Kingdom / Australia may take 7-30 working days.
5.* Canada may take 7-35 working days.
6.* France / Spain / Germany may take 7-30 working days.
7.* Eastern Europe may take 16-30 working days.
8.* Italy / Brazil / South America may take 30-50 working days.
9.* Shipped by DHL Express: 7-12 working days (you need to pay extra fee).
M195FGE-L20 Warranty:
1. We take 90 days warranty from the shipping date , no matter what quality problem it's .
2 .Please write down our email address and MSN , if you have any problem pls contact us immediately , we will help you to solve the prolbem ASAP.
M195FGE-L20 FAQ:
Q: What happen if the M195FGE-L20 I receive can't work ?
A: The M195FGE-L20 will be tested strictly before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
Q: Can You declare my order of lcd panel M195FGE-L20 at a very low value ?
A: Yes , we can . pls inform us before shipping .
Q: How long is the warranty of M195FGE-L20 ?
A: 90days warranty .
Q: Are you manufactory or trade company ?
A: WE are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
M195FGE-L20 Shipping and Package :
