7.5 Inch LCD Screen Display Module Panel LQ075V3DG01 For Sharp 640×480
Product Details:
| Place of Origin: | China |
| Brand Name: | Sharp |
| Model Number: | LQ075V3DG01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | LQ075V3DG01 | Diagonal Size: | 7.5 Inch |
|---|---|---|---|
| Pixel Format: | 640(RGB)×480 [VGA] 107PPI | Active Area: | 151.68(H)×113.76(V) Mm |
| Outline Dim.: | 179(H)×139.5(V) Mm | Bezel Area: | 156.3(H)×118.4(V) Mm |
| Weight: | 365g (Max.) | Designed For: | Industrial |
| High Light: | Sharp VGA LCD Screen Display,LQ075V3DG01 LCD Screen Display,640×480 LCD Module Panel |
||
Product Description
Original 7.5 inch For Sharp 640×480 LCD Screen Display Module Panel LQ075V3DG01
Product details :
| SHARP LCD SCREEN LQ075V3DG01 | |
| manufacturer | SHARP |
| Model Name | LQ075V3DG01 |
| screen size | 7.5inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 640(RGB)×480 VGA 107PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 151.68 × 113.76 mm (H×V) |
| physical area | 179 × 139.5 mm (H×V) |
| open area | 156.3 × 118.4 mm (H×V) |
| Contrast | Matte |
| Display | 400 cd/m² (Typ.) |
| contrast | 600:1 (Typ.) (Transmission) |
| Viewing angle | 65/65/60/55 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| Number of color | 262K |
| Reaction time | 5/21 (Typ.)(Tr/Td) ms |
| Backlight type | CCFL [1 pcs] , 50K hours, |
| Refresh rate | 60Hz |
| Touch function | No touch |
| Panel weight | 365g (Typ./Max.) |
| Signal | LVDS (1 ch, 6/8-bit) , 33pins , terminal |
| drive voltage | 3.3V (Typ.)(VCC) |
| working | Storage temperature: -30 ~ 80 °C Operating temperature: -30 ~ 80 °C |
| Original 7.5 inch For Sharp 640×480 LCD Screen Display Module Panel LQ075V3DG01 | |
Payment:
1. We accept Escrow, Alipay, Paypal, T/T(Bank Transfer), Credit Card, Western Union, Moneygram, etc....
2. If you have any problems of payment, please contact us.
Shipping and Package :
Shipping :
1. Worldwide shipping.
2. Order will be shipped within 1-3 days after receiving your money
3. Major express partners: DHL,UPS,EMS,Fedex.
4. We are not responsible for any import fees,remote area charges,taxes or other Customs fees.
Warranty:
All lcd panel enjoyed 60 days warranty. If you find the lcd is non-workable once you received, pls inform us within 7 days. We reserve the right refusing any requirement that informs the seller longer than 7 days. We will assist you the solve the problem and RMA is acceptable if problem still unsolved after communication.
Return items must have all original packaging and in good condition.
Shipping fee and Return postage and insurance charge is non-refundable.
RMA not acceptable due to ordering the wrong model.
FAQ:
Q: Can You declare my order of LQ075V3DG01 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: How to make payment of LQ075V3DG01 ?
A: We accept T/T , Paypal , western union .
Q: Do you accept sample orders of LQ075V3DG01 ?
A: Of course!sample order is welcome !
