1536*2560 LPP055A192X 5.5 Inch LCD Screen Display
Product Details:
| Place of Origin: | China |
| Brand Name: | JDI |
| Model Number: | LPP055A192X |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | LPP055A192X | Diagonal Size: | 5.5" |
|---|---|---|---|
| Pixel Format: | 1536(RGB)×2560 546PPI | Active Area: | 71.424(W)×119.04(H) Mm |
| Outline Dim.: | 73.424(H)×126.04(V)×0.55(D) Mm | Luminance: | 0 Cd/m² |
| Operating Mode: | IPS, Normally Black, Transmissive | Designed For: | Mobile Phone |
| Support Color: | 16.7M 70%NTSC | Response Time: | 40 (Max.)(Tr+Td) |
| Highlight: | QVGA LCD Screen Display,LQ038Q5DR01 LCD Screen Display |
||
Product Description
1536*2560 LPP055A192X 5.5 Inch LCD Screen Display
LPP055A192X Product details :
| Brand | JDI |
| Model P/N | LPP055A192X |
| Diagonal Size | 5.5" |
| Panel Type | LTPS TFT-LCD, CELL, COG |
| Resolution | 1536(RGB)×2560 546PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 71.424(W)×119.04(H) mm |
| Bezel Opening | - |
| Outline Dim. | 73.424(H)×126.04(V)×0.55(D) mm |
| Treatment | Hard coating (3H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 40 (Max.)(Tr+Td) |
| Viewing Angle | - |
| Operating Mode | IPS, Normally Black, Transmissive |
| Plate Thickness | 0.15+0.15 mm |
| Transmittance | 3.6% (Typ.) |
| Support Color | 16.7M 70%NTSC |
| Light Source | No B/L |
| Weight | 8.00g (Typ.) |
| Designed For | Mobile Phone |
| Frame Rate | - |
| Touch Panel | Without |
| D-IC Detail | COG Suggest S6D1HA0X01 |
| Environment | Operating Temperature: -10 ~ 60 °C; Storage Temperature: -20 ~ 80 °C |
Our company mainly specialize in LCD Display Screen , Touch Screen, Navigation, Mechanism, Board and so on. Which have so many years of export experience along with excellent quality, advanced services and competitive prices, Mingtu has won numerous customers' trust and support.
LPP055A192X Product Paramenters
* every item is as the picture showed and the title description.
* if you have any problem with the item, please contact me before you buy it, we will reply to you as soon as possible
* Each item has been checked and in good condition before shipping.
* It is shipped in protective bubble wrap and has all the protective screen coatings, so, please do not worry.
* if the item has some problem, please contact us at first time. I will help you solve problems and try our best to make you be satisified.
* happy do business with you, i think communication will solve all the problem .so, please do not be hesitate to contact us.
LPP055A192X Strong human resources.
We have a large number of employees to ensure good service for you.
All products are strictly tested before delivery, and the quality is absolutely guaranteed.
LPP055A192X Shipping and Package :
LPP055A192X Packing:
Bubble Film + Foam + Bag + Box
LPP055A192X Delivery:
DHL / UPS / TNT / FedEx ( 3 - 7 days to arrive )
EMS ( 7 - 20 days to arrive)
LPP055A192X FAQ:
Q: Can you tested the LPP055A192X before shipping ?
A: Of course , our lcd panel LPP055A192X was Strictly tested before shipping.
Q: How to order LPP055A192X ?
A: We accept T/T , Paypal , western union .
Q: How long the warranty of the lcd LPP055A192X ?
A: 90 days .
Q: What happen if the lcd panel LPP055A192X I received can't work ?
A: LPP055A192X was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
