G238HCJ-L01 23.8 Inch Industrial Open Cell LCD Panel Multi Interface VGA DVI Control Borads
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | G238HCJ-L01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | G238HCJ-L01 | Diagonal Size: | 23.8 Inch |
|---|---|---|---|
| Pixel Format: | 1920(RGB)×1080 [FHD] 92PPI | Active Area: | 527.04(H)×296.46(V) Mm |
| Outline Dim.: | 543(H)×317.4(V) Mm | Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) |
| Color Depth: | 16.7M 72% NTSC | Designed For: | Industrial |
| High Light: | G238HCJ-L01 Open Cell LCD panel,DVI Control Open Cell LCD panel |
||
Product Description
G238HCJ-L01 23.8 inch industrial open cell lcd with high definition multi interface VGA DVI control borads
Product details :
| Innolux LCD SCREEN G238HCJ-L01 | |
| manufacturer | Innolux |
| Model Name | G238HCJ-L01 |
| screen size | 23.8 inch |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 1920(RGB)×1080 [FHD] 92PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 527.04(H)×296.46(V) mm |
| Outline Dim. | 543(H)×317.4(V) mm |
| Bezel Area | 530.2(H)×299.6(V) mm |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 8/7 (Typ.)(Tr/Td) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating Mode | AAS, Normally Black, Transmissive |
| Support Color | 16.7M 72% NTSC |
| Light Source | WLED , 30K hours , W/O Driver |
| Weight | 2.71Kgs (Typ.) |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Power Supply | 5.0±0.5V |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| G238HCJ-L01 23.8 inch industrial open cell lcd with high definition multi interface VGA DVI control borads | |
Notice:
1. Each screen is tested before shipping & 100% working;Repair/Replacing old, broken, cracked,damaged faulty touch screen.
2. Please kindly leave us your exact full name (especially buyer from RU ) & Telephone No. , when you filling your informations as buyer, so that the courier can delivery the your items timely & easily.
3.When you got the package ,please make a video that when you open the package. (If there is any damage in transit, you can send this video as evidence to the dispute.)
Payment:
We accept Escrow ,Credit Card , Paypal,and so on
Shipping:
1, Pls make sure the model you need is the exact model you ordered. We shipping according to the ordered model.
2, Pls make sure the address is correct. We will ship to the address in the order. If you need to ship to different place, pls email us the address right after you made the payment.
3, Shipment will be made within 3 business days after the payment received.
4, We will test each panel strictly before shipping and make very good package of it.
5, LCD will be sent by EMS/DHL/UPS/ according to the place or customer choice.
EMS takes around 10-15 business days to arrive.
DHL/UPS take around 3-5 business days to arrive.
Russian customer attention: We can only send by EMS to Russia, EMS usually takes more days to arrive, so your patience is really appreciated.
Warranty:
All lcd panel enjoyed 60 days warranty. If you find the lcd is non-workable once you received, pls inform us within 7 days. We reserve the right refusing any requirement that informs the seller longer than 7 days. We will assist you the solve the problem and RMA is acceptable if problem still unsolved after communication.
Return items must have all original packaging and in good condition.
Shipping fee and Return postage and insurance charge is non-refundable.
RMA not acceptable due to ordering the wrong model.
FAQ:
Q: Do you accept sample orders of G238HCJ-L01 ?
A: Of course!sample order is welcome !
Q: Can I pay my order of G238HCJ-L01 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: How long will I receive my goods G238HCJ-L01?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
