AA050AA11 5.0 inch LCD Panel LVDS Connector Display lcd display panel Screen AA050AA11
Product Details:
| Place of Origin: | China |
| Brand Name: | Mitsubishi |
| Model Number: | AA050AA11 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | AA050AA11 | Diagonal Size: | 5.0 Inch |
|---|---|---|---|
| Pixel Format: | 640(RGB)×640 182PPI | Active Area: | 89.3(H)×89.3(V) Mm |
| Outline Dim.: | 103.8(H)×105.8(V) ×12.4(D) Mm | Bezel Area: | 91.28(H)×91.28(V) Mm |
| Weight: | 155g (Typ.) | Designed For: | Industrial / Outdoor High Brightness |
Product Description
AA050AA11 5.0 inch LCD Panel LVDS Connector Display lcd display panel Screen AA050AA11
Product details :
| Mitsubishi LCD SCREEN AA050AA11 | |
| Manufacturer | Mitsubishi |
| Model Name | AA050AA11 |
| Screen Size | 5.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 640(RGB)×640 182PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 89.3 × 89.3 (H×V) |
| Outline(mm) | 103.8 × 105.8 × 12.4 (H×V×D) |
| Bezel Area(mm) | 91.28 × 91.28 (H×V) |
| Treatment | Clear, Hard coating (3H) |
| Luminance | 1200 cd/m² (Typ.) |
| Contrast Ratio | 700 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/70 (Typ.)(CR≥10) |
| Response | 4/12 (Typ.)(Tr/Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 262K/16.7M 40% NTSC |
| Backlight | 2 strings WLED , 100K hours , No Driver |
| Mass | 155g (Typ.) |
| Used for | Industrial / Outdoor High Brightness |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | CMOS (1 ch, 6/8-bit) , Connector 45 pins |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
| AA050AA11 5.0 inch LCD Panel LVDS Connector Display lcd display panel Screen AA050AA11 | |
