G104XCE-L01 for 10.4 INCH 4:3 1024*768 LCD PANEL 10.4 INCH industrial lcd panel
Product Details:
| Place of Origin: | China |
| Brand Name: | CMO |
| Model Number: | G104X1-L01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model: | G104X1-L01 | Diagonal Size: | 10.4 Inch |
|---|---|---|---|
| Resolution: | 1024(RGB)×768 (XGA) 123PPI | Display Area: | 210.4 × 157.8 (H×V) |
| Outline(mm): | 225.5 × 176.3 × 10.67 (H×V×D) | Bezel Area(mm): | 215.4 × 161.8 (H×V) |
| Display Colors: | 16.2M 57% NTSC | Used For: | Industrial Gaming |
Product Description
G104XCE-L01 for 10.4 INCH 4:3 1024*768 LCD PANEL 10.4 INCH industrial lcd panel
Product details :
| CMO LCD SCREEN G104X1-L01 | |
| Manufacturer | CMO |
| Model Name | G104X1-L01 |
| Panel Size | 10.4 inch |
| Panel Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1024(RGB)×768 (XGA) 123PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 210.4 × 157.8 (H×V) |
| Outline(mm) | 225.5 × 176.3 × 10.67 (H×V×D) |
| Bezel Area(mm) | 215.4 × 161.8 (H×V) |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 400(Typ.)(cd/m²) |
| Contrast Ratio | 1200 : 1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Work Mode | Super MVA, Normally Black, Transmissive |
| Good View at | Symmetry |
| Response | 14/11 (Typ.)(Tr/Td) ms |
| Color Depth | 16.2M 57% NTSC |
| Backlight | 2 pcs CCFL , 50K hours , No Driver |
| Mass | 480g (Typ.) |
| Used for | Industrial Gaming |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 8-bit) , Connector 30 pins |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| G104XCE-L01 for 10.4 INCH 4:3 1024*768 LCD PANEL 10.4 INCH industrial lcd panel | |
Note :
We have more than 10 years experience on lcd displays filed . Our LCD Display will be tested ok before shipping . So it is very safe for you to do lcd display business with us .
Because Our company have many LCD models, we can't uploaded real product pictures for each model, but we will send you the correct products. If you are worried about product problems, you can contact us before placing an order.
Shipping Information:
1·Payment terms we only accept escrow services.
2·Items will be ship within 2 days of payment receive.
3·Standard shipping using international Airmail,Items ship from Hongkong and it takes 10-20 working days (2-4 weeks) to receive for most area.
4·If you do not receive item within 30 working days (6 weeks), please contact us to investigate the case.
Return Policy:
1·We appreciate your business and offer an instant 7 days return policy.(7 days after receive the items).
2·The returned item has to be in its original condition.
3·We are able to refund your money without shipping cost.
4·If you have any question, please contact us via Trademanager .
Notice:
1·Please be advised that the Customs Department of your country could impose duty or sales taxon your ordered item when it enters your country. we cannot be responsible for any tax or duty charged by your government on the purchase.
2·If you received a defective or incorrect item inside the parcel, please notify us and simply returnthe item for exchange.
3·Please feel free to contact me if you have any questions! We will reply to you in 24 hours.
FAQ:
Q: If I order G104X1-L01 now,when will you ship the goods ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can You declare my order of G104X1-L01 at a very low value ?
A: Yes , we can . pls inform us before shipping .
Q: How can I trace my order of G104X1-L01 ?
A: we will give you tracking number then you can trace your order from website.
Q: Can I pay my order of G104X1-L01 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
