FOR HITACHI LCD SCREEN DISPLAY TFT 7.0 inch TX18D35VM0AAA New original
Product Details:
| Place of Origin: | China |
| Brand Name: | HITACHI |
| Model Number: | TX18D35VM0AAA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | TX18D35VM0AAA | Panel Size: | 7.0" |
|---|---|---|---|
| Resolution: | 800(RGB)×480, WVGA, 133PPI | Display Area: | 152.4(W)×91.44(H) Mm |
| Bezel Opening: | 155.8(W)×94.74(H) Mm | Outline Size: | 165(W)×104(H) ×13.3(D) Mm |
| Panel Weight: | 260g (Typ.) | Used For: | Automotive Display / Industrial / Medical Imaging |
Product Description
FOR HITACHI LCD SCREEN DISPLAY TFT 7.0 inch TX18D35VM0AAA New original
Product details :
| HITACHI LCD SCREEN TX18D35VM0AAA | |
| Manufacturer | HITACHI |
| Model Name | TX18D35VM0AAA |
| Screen Size | 7.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 800(RGB)×480 (WVGA) 133PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 152.4 × 91.44 (H×V) |
| Outline(mm) | 165 × 104 × 13.3 (H×V×D) |
| Bezel Area(mm) | 155.8 × 94.74 (H×V) |
| Luminance | 450 cd/m² (Typ.) |
| Contrast Ratio | 600 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 45 (Max.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS Pro, Normally Black, Transmissive |
| Color Depth | 262K 51% NTSC |
| Backlight | 3S4P WLED , 70K hours , With LED Driver |
| Mass | 260g (Typ.) |
| Used for | Automotive Display / Industrial / Medical Imaging |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | CMOS (1 ch, 6-bit) , 40 pins Connector |
| Voltage Supply | 3.3V (Typ.)(VDD) |
| Max. Ratings | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 80 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| FOR HITACHI LCD SCREEN DISPLAY TFT 7.0 inch TX18D35VM0AAA New original | |
We mainly sell Industrial LCD panel and touch screen, provides the product information, technical consultation for all kinds of LCD screen and touch screen, We have stock 1.5-88 inches is between the various industrial screen, They are applicable to vehicle, medical equipment, injection molding machine ,industrial equipment etc. Welcome to order.
Kindly Reminder :
1.Please make sure the brand and model before buying, so as to avoid unnecessary trouble to you!
2.If the number of the need for more, please contact us, we will help you to arrange more quantity.
3.Make sure your address is correct (full name is recommended). We are not responsible for any wrong or undeliverable address.
4.We are not responsible for the possibly additional import duties, remote area charges, tax or other Customs related fee.
5.If you have any problems of payment, please contact us.
Shipping and Package :
Payment and Shipment:
1. We accept Alipay, Western Union, T/T, etc. All major credit cards are accepted through secure payment processor ESCROW
2. Item will be shipped out within 1-3 days.
3. Make sure your address is correct (full name is recommended). We are not responsible for any wrong or undeliverable address.
4. We are not responsible for the possibly additional import duties, remote area charges, taxes or other Customs related fee.
5. Delivery time:
--via DHL, Fedex, UPS: 3-7 working days
--via EMS: 7-15 working days
--via Air Mail or Parcel: 10-30 working days (sometimes longer)
About the warranty:
All items will be tested before delivery, make sure the normal work after shipment, we will provide you with a 360 - day warranty, thank you for your support and trust!
Discount:
If you order a number 100 things above, please leave a message to us, we will give you a favorable wholesale price.
FAQ:
Q: How long will I receive my goods of TX18D35VM0AAA ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment for TX18D35VM0AAA ?
A: We accept T/T , Paypal , western union .
Q: How can I trace my order of HITACHI TX18D35VM0AAA ?
A: we will give you tracking number then you can trace your order from website.
Q: Can I pay my goods TX18D35VM0AAA by credit card ?
A: Yes!you can use your credit card through your Paypal account.
