New Original ZV190E0M-N10 19.0 Inch 1280(RGB)*1024 Resolution 30 Pins LCD Display for Industrial
Product Details:
Place of Origin: | China |
Brand Name: | BOE |
Model Number: | ZV190E0M-N10 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | ZV190E0M-N10 | Screen Size: | 19.0 Inch |
---|---|---|---|
Pixel Number: | 1280(RGB)×1024 (SXGA) 86PPI | Active Area(mm): | 374.784 × 299.827 (H×V) |
Outline(mm): | 396 × 324 × 13.38 (H×V×D) | Bezel Area(mm): | 378.8 × 303 (H×V) |
Mass: | 1.80Kgs (Typ.) | Used For: | Industrial |
Product Description
New Original ZV190E0M-N10 19.0 Inch 1280(RGB)*1024 Resolution 30 Pins LCD Display for Industrial
Product details :
BOE LCD SCREEN ZV190E0M-N10 | |
Manufacturer | BOE |
Model Name | ZV190E0M-N10 |
Screen Size | 19.0 inch |
Screen Type | LCM , a-Si TFT-LCD |
Pixel Number | 1280(RGB)×1024 (SXGA) 86PPI |
Arrangement | RGB Vertical Stripe |
Active Area(mm) | 374.784 × 299.827 (H×V) |
Outline(mm) | 396 × 324 × 13.38 (H×V×D) |
Bezel Area(mm) | 378.8 × 303 (H×V) |
Luminance | 450 (Typ.)(cd/m²) |
Contrast Ratio | 1000 : 1 (Typ.) (TM) |
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
Response | 14 (Typ.)(G to G) ms |
Good View at | Symmetry |
Work Mode | ADS, Normally Black, Transmissive |
Color Depth | 16.7M 90% NTSC |
Backlight | WLED , 50K hours , With LED Driver |
Mass | 1.80Kgs (Typ.) |
Used for | Industrial |
Refresh Rate | 60Hz |
Touchscreen | Without |
Signal Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
Voltage Supply | 5.0V (Typ.) |
Max. Ratings | Storage Temp.: -20 ~ 75 °C Operating Temp.: -20 ~ 70 °C |
New Original ZV190E0M-N10 19.0 Inch 1280(RGB)*1024 Resolution 30 Pins LCD Display for Industrial |
NOTE:
1. Please confirm the model number of your LCD screen when you order our screen.So as not to buy the wrong, can not be used normally.
2.Before you confirming the screen can not work perfectly, please do not use the adhesive to install our screen to your equipment,if the screen paste the glue, we can not accept you to return it and ask for the payment refunding.
3. The problem you may meet
a.broken screen→ make an unpacking video → contact us and send the video
b. un-working screen→ make a testing video → contact us and send the video
4. If everything is OK in our screen, please leave us five stars positive feedback, we will provide you a good feedback too.
5. If the screen has any problem, please contact us immediately, we will handle it for you soon,please do not feel free to leave us the negative feedback or open a dispute, thanks for understanding.Looking forward to the long-term cooperation with you!Happy shopping!
Shipping and Package :
Packing:
the parcel will be packed well with bubble bag + strong box.Do not worry.
Shipping :
Russian Friend Pay Attention Please !!!
Please fill in receiver's full name in the order due to new policy of Russian customs,
otherwise you probably won't receive package finally .
We are not responsible for nondelivery caused by that client don't provide enough information when making order.
1.product information comes from internet,but our pictures are real,we ship your order same as our picture,so please compare our pictures with your desired product,in order to avoid trubble,As return postal costs for an incorrect purchase are at the buyer's expense
2.order will be shipped out in 2-7working days
3.Arrial time:30-60days, or even more.depends on the post service in your country.
If you didn't receive our product within 60 days, hope you can wait a few days more.
4.When you choose: package was send by " China Post Ordinary Small Packet Plus" which is can't track out of China, so hope you could wait for it patiently.thank you!
Contact Us:
Our customer service respond to inquiries via the messaging system daily on business days. We will reply your message as long as we got,so just be patient!
Our working hours are(Monday - Friday):
CN: 9 AM - 6 PM RU: 4 AM - 1 PM
AU: 11 AM - 8 PM UK: 1 AM - 10 AM
FAQ:
Q: Can you give me a discount if I need a large quantity of ZV190E0M-N10 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of ZV190E0M-N10 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: How to make payment of ZV190E0M-N10 ?
A: We accept T/T , Paypal , western union .
