8.0 inch 800×1280 TV080WXM-NS0 ft lcd screen module automotive display
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | TV080WXM-NS0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | TV080WXM-NS0 | Panel Size: | 8.0" |
|---|---|---|---|
| Resolution: | 800(RGB)×1280, WXGA, 188PPI | Display Area: | 107.64(W)×172.224(H) Mm |
| Outline Size: | 114.65(W)×183.929(H) ×3.99(D) Mm | Display Colors: | 16.7M 55% NTSC |
| Panel Weight: | 101±5g | Application: | Pad & Tablet |
Product Description
8.0 inch 800×1280 TV080WXM-NS0 ft lcd screen module automotive display
Product details :
| BOE LCD SCREEN TV080WXM-NS0 | |
| Manufacturer | BOE |
| Model Name | TV080WXM-NS0 |
| Screen Size | 8.0 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 141PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 107.64 × 172.224 (H×V) |
| Outline(mm) | 114.65 × 183.929 × 3.99 (H×V×D) |
| Treatment | Hard coating, Antireflection |
| Luminance | 450 cd/m² (Typ.) |
| Contrast Ratio | 900 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 16.7M 55% NTSC |
| Backlight | 8S3P WLED , 15K hours , No Driver |
| Mass | 101±5g |
| Used for | Pad & Tablet |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | MIPI (4 data lanes) , Connector 34 pins |
| Voltage Supply | 1.8/5.4/-5.4V (Typ.)(VDD1/PVDD/NVDD) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 65 °C |
| 8.0 inch 800×1280 TV080WXM-NS0 ft lcd screen module automotive display | |
Before buying:
Please double check your model and screen size and part number. If you are not sure about the compatibility of this product, please send us the specific model and photo of your original screen; Usually the LED panels we send are compatible models, which may not be exactly the same as your original screen model. But we can make sure it fits the model 100%. All items will be tested before shipment.
Shipping and Package :
Shipping Details:
1: Please confirm your address carefully after placing an order. We will send you the product within 3 days after receiving the payment.
2: If you do not receive the product within 45 days, please contact us. And please give us 3 working days to check the undelivered package and the reason. If it is our fault, we will refund you.
Other:
1. We are not responsible for any duties or import duties.
2: All emails will be answered within 24 hours. If you do not hear back from us, please resend your email and we will reply to you. Thank you very much!
Returns:
1: If the item is returned in its original state, it will receive a full refund.
2: No refund for damaged or missing parts.
FAQ:
Q: If I place order now,when will you ship the goods of TV080WXM-NS0 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can you give me a discount if I need a large quantity of TV080WXM-NS0 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How long will I receive my goods TV080WXM-NS0?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment of TV080WXM-NS0 ?
A: We accept T/T , Paypal , western union .
