27.0 Inch BOE Industrial LCD Panel Display Medical Image Display Screen HR270WU1-200
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | HR270WU1-200 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | HR270WU1-200 | Panel Size: | 27.0" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD, 81PPI | Display Area: | 597.888(W)×336.312(H) Mm |
| Bezel Opening: | 603.9(W)×342.3(H) Mm | Outline Size: | 630(W)×368.2(H) ×15.7(D) Mm |
| Weight: | 3.00Kgs (Typ.) | Application: | Industrial / Medical Imaging |
| High Light: | 27.0 inch Industrial LCD Panel Display,HR270WU1-200 Industrial LCD Panel Display,Medical Imaging industrial LCD panel BOE |
||
Product Description
27.0 inch BOE industrial LCD panel Medical image display screen HR270WU1-200
Product details :
| BOE LCD SCREEN HR270WU1-200 | |
| Manufacturer | BOE |
| Model Name | HR270WU1-200 |
| Screen Size | 27.0 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 81PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 597.888 × 336.312 (H×V) |
| Outline(mm) | 630 × 368.2 × 15.7 (H×V×D) |
| Bezel Area(mm) | 603.9 × 342.3 (H×V) |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 725 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 14 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 1.07B 100% sRGB |
| Backlight | 14S4P×2CN WLED , 30K hours , No Driver |
| Mass | 3.00Kgs (Typ.) |
| Used for | Industrial / Medical Imaging |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 10-bit) , 51 pins Connector |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| 27.0 inch BOE industrial LCD panel Medical image display screen HR270WU1-200 | |
Special Notice:
Please test normal before installation.
As the touch screen may has different connector cable for the same model.
Please open your screen to check if your cable is the same as the picture.
Different production batches. Product part number and LOGO may not be consistent with the picture. We only guarantee compatibility
Warm tips:
Please do not hasitate to contact us if you have any questions or concerns before or after your purchase.We are committed to your 100% Satisfaction .
Please contact your local postal office for the delivery as soon as you get the information that the part already in your country !
Please make sure to leave us your exact full name and telephone no when filling your buyer information so that the shipping company can get you easily !
In case any mistake please open your machine and confirm the part is the exact one you need .If you are not sure we are here for you at any time !
Payment Terms:
Full payment must be paid within 7 days after placing your order .
We will make delivery of the goods within 3 working days after receiving your paymen
Shipping and Package :
Shipping and Handling:
Make sure your shipping address and the telephone information is correct .
HK POST,SG POST,DHL ,FEDEX,TNT,UPS and EMS are available .
We will provide the tracking no for all the shipping method.You can track it on their official wesite.
Buyers from Brazil need to provide CPF number in advance if you choose DHL or UPS,otherwise,we have to ship via EMS
Except HK/SG post only use EMS for Russia buyers .
All the buyers need to pay extra fee for remote area service by DHL,UPS or Fedex ,but no need for EMS .
Refund&Exchange:
If you are not satisfied with your purchase , you can exchange the items received but you must contact us within 3days of the receipt of your order ,but you should pay all additional shipping fee incurred and the items returned should be kept in their original status .
If you wish to exchange defective or incorrect shipped goods please contact us within 3days after receiving the goods .
Please note that for exchange part we will ship it out as soon as we get the returned one
Contact Us:
1. If there's any problem, please do not hesitate to contact us by message, we will reply you within 1 business day. (not include Public holiday)
2. Working Hours: Monday to Saturday
3. If you don't get response within 1-2 business days, please check your email or My Messages in case your email provider has an overly aggressive spam filter blocking or my emails. Please add us in your contact and email us again.
4. Bulk order is acceptable, lower prices will be offered to you for bulk order.
FAQ:
Q: Can You declare my order of HR270WU1-200 at a very low value ?
A: Yes , we can . pls inform us before shipping .
Q: How long is the warranty of BOE HR270WU1-200 ?
A: 90 days warranty .
Q: Can you give me a discount if I need a large quantity of HR270WU1-200 ?
A: Of course!If you make a large order, we will give you a discount.
Q: I do not find the LCD I am looking for in the website, what should I do ?
A: You can give us some pictures,we have a lot of LCD out of shelves.
