HR230WU1-400 23.0 Inch WLED TFT LCD Screen Panel RGB 1920X1080 For Desktop Monitor
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | HR230WU1-400 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | HR230WU1-400 | Panel Size: | 23.0" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD, 95PPI | Display Area: | 509.184(W)×286.416(H) Mm |
| Bezel Opening: | 513.0(W)×291.0(H) Mm | Outline Size: | 533.2(W)×312(H) ×11(D) Mm |
| Panel Weight: | 2.39Kgs (Typ.) | Application: | Desktop Monitor |
| High Light: | HR230WU1-400 TFT LCD Screen Panel,WLED TFT LCD Screen Panel,Desktop Monitor TFT LCD Screen Panel |
||
Product Description
HR230WU1-400 23.0 inch 1920(RGB)×1080 WLED TFT-LCD Screen Panel for Desktop Monitor
Product details :
| BOE LCD SCREEN HR230WU1-400 | |
| Manufacturer | BOE |
| Model Name | HR230WU1-400 |
| Screen Size | 23.0 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 95PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 509.184 × 286.416 (H×V) |
| Outline(mm) | 533.2 × 312 × 11 (H×V×D) |
| Bezel Area(mm) | 513.0 × 291.0 (H×V) |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 14 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | FFS, Normally Black, Transmissive |
| Color Depth | 16.7M 99% sRGB |
| Backlight | 4 strings WLED , 30K hours , No Driver |
| Mass | 2.39Kgs (Typ.) |
| Used for | Desktop Monitor |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| HR230WU1-400 23.0 inch 1920(RGB)×1080 WLED TFT-LCD Screen Panel for Desktop Monitor | |
Note:
The screens you are purchasing are used, may have signs of use, such as scratches or marks, but we already tested them before shipping, so don’t worry about the quality.
Shipping and Package :
Shipping :
1, Shipping via China Post Registered Air Mail or ePacket.
2, We will send out your goods within 3 working days after we get your order .
3, Normally , you can get the goods within 27 calendar days .
4, Please make sure your shipping information ( including address / post code / phone number / contact person ) are correct before order . If you want us send it to another address , pls inform us in advance , and leave message in our transaction.
Warranty :
1. We offer warranty for all of our products.
2. Buyers bear the shipping cost for returning defective or non-defective item to us.
3. Return items should be in good condition same as we sent, not damaged.
4. Returned items are subject to approval by us, it should be in original box as we sent.
5. Physically damaged items received should be reported within 2 days.
6. All NON-Seller Mistake returns, there is 15% re-stocking fees and shipping and handling charges are NON-refundable. (E.g. you boughtwrong item)
Contact Us:
1. If there's any problem, please do not hesitate to contact us by message, we will reply you within 1 business day. (not include Public holiday)
2. Working Hours: Monday to Saturday
3. If you don't get response within 1-2 business days, please check your email or My Messages in case your email provider has an overly aggressive spam filter blocking or my emails. Please add us in your contact and email us again.
4. Bulk order is acceptable, lower prices will be offered to you for bulk order.
FAQ:
Q: How can I trace my order of BOE HR230WU1-400 ?
A: we will give you tracking number then you can trace your order from website.
Q: Can I pay my goods HR230WU1-400 by credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How do you ship my goods BOE HR230WU1-400 ?
A: We can shipping all over the world.via DHL,UPS,Fedex and EMS.
Q: What happen if the HR230WU1-400 I receive can't work ?
A: The BOE HR230WU1-400 will be tested strictly before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
