DV550FHM-NN0 55.0 Inch IPS LCD Display FHD 1920×1080 TFT LCD Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | DV550FHM-NN0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | DV550FHM-NN0 | Panel Size: | 55 Inch |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080 (FHD) 40PPI | Active Area(mm): | 1209.6 × 680.4 (H×V) |
| Outline(mm): | 1230.4 × 706.8 × 40.2 (H×V×D) | Contrast Ratio: | 1200 : 1 (Typ.) (TM) |
| Mass: | 13.3Kgs (Typ.) | Used For: | Digital Signage |
| High Light: | DV550FHM-NN0 IPS LCD display,55.0 inch IPS LCD display,1920×1080 TFT LCD panel |
||
Product Description
DV550FHM-NN0 55.0 inch FHD 1920×1080 IPS display tft LCD panel
Product details :
DV550FHM-NN0 supports display 1920(RGB)×1080 (FHD) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 1209.6(W)×680.4(H) mm, outline size of 1230.4(W)×706.8(H)×40.2(D) mm, with surface treament of Antiglare (Haze 1%), Hard coating (3H), net weight of 13.3Kgs (Typ.). As a ADS, Normally Black, Transmissive LCM product, DV550FHM-NN0 can provides 350 cd/m² display brightness 1200:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 8 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 30K hours, With LED Driver. DV550FHM-NN0 utilizes LVDS (2 ch, 8-bit) as it's signal inputting systerm, which connected by 51 pins Connector with power supply voltage of 12.0V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.
| BOE LCD SCREEN DV550FHM-NN0 | |
| Manufacturer | BOE |
| Model Name | DV550FHM-NN0 |
| Screen Size | 55 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 40PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 1209.6 × 680.4 (H×V) |
| Outline(mm) | 1230.4 × 706.8 × 40.2 (H×V×D) |
| Treatment | Antiglare (Haze 1%), Hard coating (3H) |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 1200 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 8 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 16.7M 72% NTSC |
| Backlight | WLED , 30K hours , With LED Driver |
| Mass | 13.3Kgs (Typ.) |
| Used for | Digital Signage |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| DV550FHM-NN0 55.0 inch FHD 1920×1080 IPS display tft LCD panel | |
Payment:
1. We accept T/T(bank transfer), Western Union, Paypal for now.
2. Choosing Paypal need to pay extra 3% of total amount as handling charge.
3. If you have any problems of payment, please contact us freely.
Shipping and Package :
Packaging and Delivery:
1. Packaging Details: Carton, Capboard, EPE, Blister Tray. About how many products can be contained in one package, it is up to different size of the products.
2. Delivery Details: 1 to 30 days. The delivery fee is up to the weight and volume of the products.
Shipment:
1.The goods will be shipped within 1-2 working days after payment is received.
2. The goods can be shipped by DHL, FedEx, UPS,EMS ,TNT, DPEX, ARAMEX, Registered post, Air or your shipping agent. Please choose the shipment method you prefer.
3. The buyer is responsibel for any tax or duty charged by their country.
Return/Refund :
1.We provide different warranty for different products.
2. Please inform us within 7 days if you receive any defective goods from us. The returned items has to be its original condition to qualify for a refund or replacement.
FAQ:
Q: Can You declare my order of DV550FHM-NN0 at a very low value ?
A: Yes , we can . pls inform us before shipping .
Q: How long is the warranty of DV550FHM-NN0 ?
A: 90days warranty .
Q: Do you accept sample orders for DV550FHM-NN0 ?
A: Of course!sample order is welcome !
Q: How long will I receive my goods of DV550FHM-NN0 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
