12.5 Inch TFT LCD Screen Module 1366X768 WXGA M125NWN1 R0 12.1" TFT LCD Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | IVO |
| Model Number: | M125NWN1 R0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | M125NWN1 R0 | Panel Size: | 12.1" |
|---|---|---|---|
| Resolution: | 1366(RGB)×768 (WXGA) 125PPI | Viewing Angle: | 45/45/15/35 (Typ.)(CR≥10) |
| Color Depth: | 262K 55% NTSC | Application: | Industrial |
| High Light: | WXGA tft lcd screen module,M125NWN1 R0 tft lcd screen module,125PPI tft lcd panel |
||
Product Description
12.5 inch 1366*768 M125NWN1 R0 (IVO04E3) tft lcd screen module tft screen lcd display
Product details :
| IVO LCD SCREEN M125NWN1 R0 | |
| Manufacturer | IVO |
| Model Name | M125NWN1 R0 |
| Screen Size | 12.5 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1366(RGB)×768 (WXGA) 125PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 276.615 × 155.52 (H×V) |
| Outline(mm) | 290.5 × 181.4 × 3 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 200 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Min.) (TM) |
| Viewing Angle | 45/45/15/35 (Typ.)(CR≥10) |
| Response | 3/5 (Typ.)(Tr/Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 262K 47% NTSC |
| Backlight | WLED , 15K hours , With LED Driver |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | eDP (1 Lane) , eDP1.2 30 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| 12.5 inch 1366*768 M125NWN1 R0 (IVO04E3) tft lcd screen module tft screen lcd display | |
Customer Service Policy:
We are more than happy to answer any questions that you have, please contact with
1:Orders processed timely after the payment verification.
2:We only ship to confirmed order addresses. Your order address MUST MATCH your Shipping address.
3:If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction!
4:Due to stock status and time differences, we will choose to ship your item from our first available warehouse for fast delivery.
About Shipping:
When you place an order, please choose a shipping method and pay for the order including the shipping fee. We will send the items within 5 days once your payment is completed.
We do not uarantee delivery time on all international shipments due to differences in customs clearing times in individual countries, which may affect how quickly your product is inspected. Please note that buyers are responsible for all additional customs fees, brokerage fees, duties, and taxes for importation into your country. These additional fees may be collected at time of delivery. We will not refund shipping charges for refused shipments.
The shipping cost does not include any import taxes, and buyers are responsible for customs duties.
All order will ship out in 1-5 buiness after payment verify .Pls wait in patient.
China Post mail is not fast , Usally need 15-60days arriived.If in urgent .Pls choose DHL/ Fedex/EMS.We can write low value for cutomer if in need!
China Post Ordinary Small Packet Plus just can track to the domestic of our country,but it not effect your receiving.
If you want your products and don't want to waste your time, pls choose China Post Registered Air Mail. If you choose China Post Ordinary Small Packet Plus and the package is lost. We will prove you we send the package and we only can refound 50%. This is your choose, We all have to take risks. If you can't agree, pls don't buy.
China Post Ordinary Small Packet Plus and China Post Registered Air Mail all can track in www.17track.net/en/
Letter to Buyer:
Dear customers, if you can't confirm your screen machine, please send photos to the screen. We can confirm your screen by pictures. We can confirm your screen by pictures. Professional LCD supplier, we have many screens. If you want any screen, give us the information, because of the time difference, we will respond to the information, once we see the information, thank you for looking. Well, I give you my best wishes.
Attention:
If you can't confirm which one,please give me your original LCD SCREEN pictures to us.Thanks
Before you ordered , in case of any mistake & trouble in our business , please mail us as below information for double confirming to win this deal together.
•1-->LCD model name in your hand now ,such as : LP140WH1-TLA1
•2-->Your laptop name ,such as : DV3000 ......
•3-->Send above information to our mail and we will response you within 24 hours for quick and right deal ,thanks !
FAQ:
Q: I do not find the LCD I am looking for in the website, what should I do ?
A: You can give us some pictures,we have a lot of LCD out of shelves.
Q: How long will I receive my goods of M125NWN1 R0 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment for M125NWN1 R0 ?
A: We accept T/T , Paypal , western union .
Q: What happen if the M125NWN1 R0 I receive can't work ?
A: The M125NWN1 R0 will be tested strictly before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
Return:
Customer has 7 days to inspect/install the product upon delivery. Please report any damage or dead-on-arrial (DOA) during the period.
Customer may exchange for same exact product within 90-day, when it is determined defects. When exchanging for a different product, customer is considered to conduct two separate transactions, a return and a purchase.
