• M121MNS1 R1 12.1 Inch Industrial LCD Panel Display RGB 800X600 SVGA 82PPI 450 Cd/M2 LVDS Input
  • M121MNS1 R1 12.1 Inch Industrial LCD Panel Display RGB 800X600 SVGA 82PPI 450 Cd/M2 LVDS Input
  • M121MNS1 R1 12.1 Inch Industrial LCD Panel Display RGB 800X600 SVGA 82PPI 450 Cd/M2 LVDS Input
M121MNS1 R1 12.1 Inch Industrial LCD Panel Display RGB 800X600 SVGA 82PPI 450 Cd/M2 LVDS Input

M121MNS1 R1 12.1 Inch Industrial LCD Panel Display RGB 800X600 SVGA 82PPI 450 Cd/M2 LVDS Input

Product Details:

Place of Origin: China
Brand Name: IVO
Model Number: M121MNS1 R1

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Delivery Time: 7 Days
Payment Terms: T/T, Western Union
Supply Ability: 100000 Unit/Units per Month
Get Best Price Contact Now

Detail Information

Panel Model: M121MNS1 R1 Panel Size: 12.1"
Resolution: 800(RGB)×600 (SVGA) 82PPI Display Area: 246 × 184.5 (H×V)
Bezel Opening: 249 × 187.5 (H×V) Outline Size: 276 × 209 × 9.6 (H×V×D)
Color Depth: 262K 55% NTSC Application: Industrial
High Light:

M121MNS1 R1 Industrial LCD Panel Display

,

SVGA Industrial LCD Panel Display

,

LVDS Input 12.1 inch LCD panel

Product Description

12.1 inch LCD panel M121MNS1 R1 support800(RGB)*600 SVGA 82PPI



Product details :

IVO LCD SCREEN M121MNS1 R1
Manufacturer IVO
Model Name M121MNS1 R1
Screen Size 12.1 inch
Screen Type a-Si TFT-LCD, LCM
Pixel Number 800(RGB)×600 (SVGA) 82PPI
Arrangement RGB Vertical Stripe
Active Area(mm) 246 × 184.5 (H×V)
Outline(mm) 276(H)×209(V) ×9.6(D) mm
Bezel Area(mm) 249.0(H)×187.5(V) mm
Treatment Antiglare, Hard coating (3H)
Luminance 450 cd/m² (Typ.)
Contrast Ratio 800 : 1 (Min.) (TM)
Viewing Angle 80/80/60/80 (Typ.)(CR≥10)
Response 7/23 (Typ.)(Tr/Td) ms
Good View at 6 o'clock
Work Mode TN, Normally White, Transmissive
Color Depth 262K 55% NTSC
Backlight WLED , 50K hours , With LED Driver
Mass 700g (Max.)
Used for Industrial
Refresh Rate 60Hz
Touchscreen Without
Signal Type LVDS (1 ch, 6-bit) , 20 pins Connector
Voltage Supply 3.3V (Typ.)
Max. Ratings Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
12.1 inch LCD panel M121MNS1 R1 support800(RGB)*600 SVGA 82PPI 450 cd/m lvds input 60HZ LCD screen



Customer Service Policy:


We are more than happy to answer any questions that you have, please contact with


1:Orders processed timely after the payment verification.


2:We only ship to confirmed order addresses. Your order address MUST MATCH your Shipping address.



3:If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction!


4:Due to stock status and time differences, we will choose to ship your item from our first available warehouse for fast delivery.







About Shipping:





When you place an order, please choose a shipping method and pay for the order including the shipping fee. We will send the items within 5 days once your payment is completed.



We do not uarantee delivery time on all international shipments due to differences in customs clearing times in individual countries, which may affect how quickly your product is inspected. Please note that buyers are responsible for all additional customs fees, brokerage fees, duties, and taxes for importation into your country. These additional fees may be collected at time of delivery. We will not refund shipping charges for refused shipments.



The shipping cost does not include any import taxes, and buyers are responsible for customs duties.

All order will ship out in 1-5 buiness after payment verify .Pls wait in patient.

China Post mail is not fast , Usally need 15-60days arriived.If in urgent .Pls choose DHL/ Fedex/EMS.We can write low value for cutomer if in need!



China Post Ordinary Small Packet Plus just can track to the domestic of our country,but it not effect your receiving.


If you want your products and don't want to waste your time, pls choose China Post Registered Air Mail. If you choose China Post Ordinary Small Packet Plus and the package is lost. We will prove you we send the package and we only can refound 50%. This is your choose, We all have to take risks. If you can't agree, pls don't buy.


China Post Ordinary Small Packet Plus and China Post Registered Air Mail all can track in www.17track.net/en/



Letter to Buyer:



Dear customers, if you can't confirm your screen machine, please send photos to the screen. We can confirm your screen by pictures. We can confirm your screen by pictures. Professional LCD supplier, we have many screens. If you want any screen, give us the information, because of the time difference, we will respond to the information, once we see the information, thank you for looking. Well, I give you my best wishes.





Attention:



If you can't confirm which one,please give me your original LCD SCREEN pictures to us.Thanks



Before you ordered , in case of any mistake & trouble in our business , please mail us as below information for double confirming to win this deal together.



•1-->LCD model name in your hand now ,such as : LP140WH1-TLA1



•2-->Your laptop name ,such as : DV3000 ......



•3-->Send above information to our mail and we will response you within 24 hours for quick and right deal ,thanks !





FAQ:



Q: What happen if the M121MNS1 R1 I receive can't work ?

A: The M121MNS1 R1 will be tested strictly before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.



Q: Can You declare my order of lcd panel M121MNS1 R1 at a very low value ?

A: Yes , we can . pls inform us before shipping .



Q: How long is the warranty of M121MNS1 R1 ?

A: 90days warranty .



Q: Are you manufactory or trade company ?

A: WE are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.





Delivery time:



Your bag will be cleared after 1-3 business days of payment.



Packing and delivery time:



We have a professional software package team. We'll tighten your package and let him give you Afely, so you don't have to worry about it.

1. Epacket: It usually takes 10 to 20 working days to receive the package.

2. EMS: It usually takes 7-10 working days to get a package.

3. DHL: It usually takes 5-7 working days to receive your mail.

4. China post: It usually takes 15-40 days. Brazil may need several days to receive the package.





Shipping and Package :

M121MNS1 R1 12.1 Inch Industrial LCD Panel Display RGB 800X600 SVGA 82PPI 450 Cd/M2 LVDS Input 0
