NL192108BC18-06F Industrial LCD Display 15.6 Inch FHD LCD Screen Module
Product Details:
| Place of Origin: | China |
| Brand Name: | NEC |
| Model Number: | NL192108BC18-06F |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | NL192108BC18-06F | Screen Size: | 15.6 Inch |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080 (FHD) 141PPI | Active Area(mm): | 344.16 × 193.59 (H×V) |
| Outline(mm): | 363.8 × 215.9 × 16.2 (H×V×D) | Bezel Area(mm): | 347.55 × 196.75 (H×V) |
| Mass: | 1.05/1.15Kgs (Typ./Max.) | Application: | Industrial / Outdoor High Brightness |
| High Light: | NL192108BC18-06F Industrial LCD Display,141PPI Industrial LCD Display,Antiglare LCD screen module |
||
Product Description
NL192108BC18-06F LCD Displays Accessories 15.6 inch FHD LED Display screen module
Product details :
| NLT LCD SCREEN NL192108BC18-06F | |
| manufacturer | NLT |
| Model Name | NL192108BC18-06F |
| screen size | 15.6 inch |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 1920(RGB)×1080, FHD, 141PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 344.16(W)×193.59(H) mm |
| physical dimension | 363.8(W)×215.9(H) ×16.2(D) mm |
| Visual size | 347.55(W)×196.75(H) mm |
| surface treatment | Antiglare, Hard coating (3H) |
| Brightness | 1500 cd/m² (Typ.) |
| Contrast | 750:1 (Typ.) (TM) |
| Best angle | Symmetry |
| Optical mode | UA-SFT, Normally Black, Transmissive |
| Viewing angle | 88/88/88/88 (Typ.)(CR≥10) |
| Responding time | 15/15 (Typ.)(Tr/Td) |
| Number of color | 16.7M 40% NTSC |
| Backlight type | 4 strings WLED , 50K hours , Without Driver |
| Panel weight | 1.05/1.15Kgs (Typ./Max.) |
| Apply to | Industrial / Outdoor High Brightness |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | eDP (2 Lanes) , HBR1 (2.7G/lane) , 40 pins Connector |
| Supply voltage | 3.3V (Typ.) |
| Maximum rating | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 85 °C |
| NL192108BC18-06F TFT Displays Accessories 15.6 inch FHD LED Display screen module | |
Useful news:
1. Our parts can guarantee a warranty period of more than 90 days. If the parts are damaged due to improper operation, there is no warranty.
2. regarding payment, we can accept bank transfer, PayPal, Western Union, quick cash, Alipay and Ecrow terms.
3. The price is quoted at the right time, but may be changed one week later due to exchange rate fluctuations and changes in order quantity.
4. If you receive some items of imperfect quality, we will resiponsibly arrange for a refund or replacement. But objects must remain in their original state.
5. Inventory availability is subject to previous sales. All references are new and unused, original packaging, unless specified.
6. Prior to the order RE-VALIDATE offer.
Payment:
1. We accept T/T(bank transfer), Western Union, Paypal for now.
2. Choosing Paypal need to pay extra 3% of total amount as handling charge.
3. If you have any problems of payment, please contact us freely.
Shipping and Package :
Logistics:
1. Worldwide shipping.
2. Orders will be delivered in 3 working days after receiving full payment.
3. Major express partners: DHL, Fedex, TNT, EMS, Aramex.
4. We are not responsible for any customs duties and additional taxes.
Refund&Replacement:
1. Please contact us within 7 days if you have any question after you receiving the items.
2.The returned items has to be in its original condition, specific reason for the return,
We will issue a return or replacement for your order after we received the returns.
3.The buyer is responsible for all the shipping cost incurred.
FAQ:
Q: How can I trace my order of NL192108BC18-06F ?
A: we will give you tracking number then you can trace your order from website.
Q: How long will I receive my goods NL192108BC18-06F ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Do you accept sample orders of NL192108BC18-06F ?
A: Of course!sample order is welcome !
Q: Can I pay my order of NL192108BC18-06F via credit card ?
A: Yes!you can use your credit card through your Paypal account.
