12.1 inch 800*600 LTD121C31S tft screen lcd display tft lcd display module
Product Details:
| Place of Origin: | China |
| Brand Name: | Toshiba Matsushita |
| Model Number: | LTD121C31S |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LTD121C31S | Diagonal Size: | 12.1 Inches |
|---|---|---|---|
| Resolution: | 800(RGB)×600, SVGA, 82PPI | Display Area: | 246(W)×184.5(H) Mm |
| Viewing Angle: | 60/60/50/50 (Typ.)(CR≥10) | Display Colors: | 262K |
Product Description
12.1 inch 800*600 LTD121C31S tft screen lcd display tft lcd display module
Product details :
| Toshiba Matsushita LCD SCREEN LTD121C31S | |
| Manufacturer | Toshiba Matsushita |
| Model Name | LTD121C31S |
| Panel Size | 12.1’’ |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 800(RGB)×600, SVGA, 82PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 246(W)×184.5(H) mm |
| Bezel Opening | 249.0(W)×187.5(H) mm |
| Outline Size | 278.3(W)×209(H) ×11(D) mm |
| Brightness | 250 cd/m² (Typ.) |
| Contrast Ratio | 450:1 (Typ.) (TM) |
| Viewing Angle | 60/60/50/50 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 10/25 (Typ.)(Tr/Td) |
| Display Colors | 262K |
| Lamp Type | 2 pcs CCFL , 50K hours , Without Driver |
| Touch Screen | Without |
| Panel Weight | 670g (Typ.) |
| Application | Industrial |
| Signal Interface | CMOS (1 ch, 6-bit) , 32 pins Connector |
| Input Voltage | 3.3V (Typ.)(VDD) |
| Environment | Operating Temp.: -10 ~ 65 °C ; Storage Temp.: -20 ~ 80 °C |
| 12.1 inch 800*600 LTD121C31S tft screen lcd display tft lcd display module | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Feedback:
1, When you get the goods , pls confirm that you have got the goods .
2, If you are satisfied with our products and service, please give us your positive feedback, that will be appreciated.
3, If you have any problem please contact us before giving any feedback , pls let us know about the problem . We will try our best to solve the problem for you ASAP. . Customers' satisfaction is very important to us .
Please let us know your requirements on panels
1), Size
2), Resolution
3), Brightness/Luminance
4), Viewing Angle
5), Light Source
6), Signal Interface: LVDS or eDP or V-by-One
or tell us the exact model # for reference.
we will quote the same model # or recommend alternatives when we couldn't provide the exact model or when we think there is a better choice for you.
Please Note:
All LCD panels are the original brand new coming from the original factory or its distributor , the quality should meet the incoming inspection standard( IIS)
please rest assured that you will buy the best product . All of our company’s products are under strict tested. It will be under burned-in test within 48 hours .
FAQ:
Q: How long will I receive my goods LTD121C31S ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q:If I place order now,when will you ship the goods of LTD121C31S ?
A: The order will be shipped within 2-3 working days after received your payment.
Q:Do you accept sample orders of LTD121C31S ?
A:Of course!sample order is welcome !
Q: How long is the warranty ?
A: We offer 90days warranty .
Reminder :
Our price is not including any customs tax / fee in the destination . You need to pay some tax / fee or not , when the goods get Clearance Customs in the destination Customs , It depends the laws in the destination country .
After service:
We can accept a 5-days return without reasons, and promise a warranty of 90 days for this item, and the shipping cost of returning should be afforded by the buyer.
Such as man-made factors, natural disasters caused damage will not in our warranty. For example: the installed improper, Nick, the tube touch bad, feed, etc... Store the selling of commodities have posted the warranty fragile tags, such as warranty tags in guarantee period be torn up. Disconnect or loss shall be deemed to be giving up the warranty, and we shall not accept any responsibility. Please attention!
Feedback:
All products are tested before delivery, providing 90 days of quality assurance service. Quality problems are subject to warranty at any time!
You can track the shipment with the tracking number we give to you. If you can't get the status of your shipment or you find the status of your shipment abnormal, please feel free to contact us.
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
