NL10276BC13-01 Original 6.5 inch LCD Screen for Industrial Equipment for NEC
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | NEC |
| Model Number: | NL10276BC13-01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton + Foam Cotton |
| Delivery Time: | 5 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 600 Unit/Units per Month |
|
Detail Information |
|||
| Model: | NL10276BC13-01 | Diagonal Size: | 6.5 Inch |
|---|---|---|---|
| Pixel Format: | 1024(RGB)×768 [XGA] 196PPI | Active Area: | 132.096(H)×99.072(V) Mm |
| Outline Dim.: | 153(H)×118(V) ×9.5(D) Mm | Bezel Area: | 135.9(H)×102.8(V) Mm |
| Weight: | 165/185g (Typ.) | Designed For: | Industrial |
Product Description
NL10276BC13-01 Original 6.5 inch LCD Screen for Industrial Equipment for NEC
Product details :
| NEC LCD Screen NL10276BC13-01 | |
| manufacturer | NEC |
| Model Name | NL10276BC13-01 |
| Screen Size | 6.5 inch |
| Panel type | a-Si TFT-LCD, LCD module |
| Number of pixels | 1024(RGB)*768, XGA, 196PPI |
| Pixel layout | RGB vertical bar |
| Display area | 132.096(W)*99.072(H) mm |
| Viewable area | 135.9(W)*102.8(H) mm |
| physical dimension | 153(W)*118(H) *9.5(T) mm |
| Surface treatment | Clear, Hard coating (3H) |
| Panel brightness | 500 cd/m² (Typ.) |
| Contrast | 500:1 (Typ.) (TM) |
| Viewing angle | 80/80/80/60 (Typ.)(CR≥10) |
| Operating mode | TN, normally white display, transmissive |
| Best perspective | 6 o'clock |
| Reaction time | 6/19 (Typ.)(Tr/Td) ms |
| Display color | 262K/16.7M, 36% NTSC |
| type of light source | 6 strings WLED, 16K hours, without driver |
| working frequency | 60Hz |
| touch screen | No touch |
| Panel weight | 165/185g (Typ.) |
| Signal interface | LVDS (1 ch, 6/8-bit), 20 pins, connector |
| Drive screen voltage | 3.3V (Typ.) |
| working environment | Work: -20 ~ 70 °C; Storage: -30 ~ 80 °C; Vibration resistance: 2.0G (19.6 m/s²) |
| NL10276BC13-01 Original 6.5 inch LCD Screen for Industrial Equipment for NEC | |
Our advantages:
1: We are all own stock, with adequate supply
2: The quality of the product reached a series of certification
3: We support a variety of transportation, Hong Kong and the Chinese postal packets, EMS.DHL federal .UPS and TNT, can fully meet the different needs of the buyer.
I firmly believe
We will be your best partner
Shipping and Package :
Shipping :
1. Worldwide Shipping. (except some countries and APO/FPO)
2. The order will be processed in time after payment is confirmed.
3. We only ship to the confirmed order address. Your order address must match your shipping address.
4. Service transit time is provided by the carrier, excluding weekends and holidays. Shipping times may vary, especially during holidays.
5. If you do not receive your goods within 30 days after payment, please contact us. We will track the shipment and get back to you as soon as possible? Our goal is to keep our customers happy!
6. Due to stock status and time difference, we will choose to ship from our first available warehouse for fast delivery.
Warranty & Return:
Thanks for your great support and trust to our products, we have very strict quality control system, so we have extremely low defect rate.
However, if you want to return the item, please follow these instructions:
1. As a responsible seller, we will try our best to solve every problem.Please Email us
2. International transport can sometimes cause product damage or product failure
If you find such a problem,resolved through our emails or phone calls; we will be here for you all the time!.
I will help you solve the problem as soon as possible.
3. We stand behind all of our products with a 30-day, money-back or exchange guarantee.
FAQ :
Q: Can You declare my order of NL10276BC13-01 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: Can you give me a discount if I need a large quantity of NL10276BC13-01 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How to make payment of NL10276BC13-01 ?
A: We accept T/T , Paypal , western union .
Q: How long is the warranty ?
A: We offer 90 days warranty .
