NL8060BC26-17 touch screen LCD display TFT Module 10.4 inch 800(RGB)×600
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | NEC |
| Model Number: | NL8060BC26-17 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton + Foam Cotton |
| Delivery Time: | 5 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 600 Unit/Units per Month |
|
Detail Information |
|||
| Model: | NL8060BC26-17 | Diagonal Size: | 10.4 Inch |
|---|---|---|---|
| Pixel Format: | 800(RGB)×600 [SVGA] 96PPI | Active Area: | 211.2(H)×158.4(V) Mm |
| Outline Dim.: | 243(H)×185.1(V) Mm | Bezel Area: | 215.4(H)×161.8(V) Mm |
| Weight: | 520/550g (Typ./Max.) | Designed For: | Industrial |
Product Description
NL8060BC26-17 touch screen LCD display TFT Module 10.4 inch 800(RGB)×600
Product details :
| NEC LCD Screen NL8060BC26-17 | |
| manufacturer | NEC |
| Model Name | NL8060BC26-17 |
| Screen Size | 10.4 inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 800(RGB)*600 [SVGA] 96PPI |
| Pixel configuration | RGB vertical bar |
| Display size | 211.2 * 158.4 mm (H*V) |
| physical dimension | 243 * 185.1 mm (H*V*D) |
| Visual size | 215.4 * 161.8 mm (H*V) |
| Surface treatment | Anti-reflective treatment |
| Brightness (cd/m²) | 280 (Typ.) |
| Contrast | 300: 1 (Typ.) [Transmission] |
| Best angle | 6 o'clock |
| Optical mode | TN, normally white display, transmissive |
| Viewing angle | 50/50/35/45 (Typ.)(CR≥10) |
| responding speed | 15/65 (Typ.)(Tr/Td) ms |
| Number of colors | 262K, 43% NTSC |
| Backlight type | 2 pcs CCFL, without driver |
| Screen weight | 520/550g (Typ./Max.) |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | CMOS (1 ch, 6-bit), connector, 41 pins |
| Supply voltage | 3.3/5.0V (Typ.)(VCC) |
| Maximum rating | Storage temperature: -20 ~ 60 °C Working temperature: 0 ~ 50 °C; Vibration resistance: 2.0G (19.6 m/s²) |
| NL8060BC26-17 touch screen LCD display TFT Module 10.4 inch 800(RGB)×600 | |
