29 inch Industrial LCD Display Panels LM290WW2-SSA1 2560*1080
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | LG Display |
| Model Number: | LM290WW2-SSA1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton + Foam Cotton |
| Delivery Time: | 5 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 600 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | LM290WW2-SSA1 | Panel Size: | 29.0 Inch |
|---|---|---|---|
| Pixel Format: | 2560(RGB)×1080 [CSHD] 96PPI | Active Area: | 672.768(H)×283.824(V) Mm |
| Outline Dim.: | 693.6(H)×308.9(V) ×17.5(D) Mm | Response Time: | 14 (Typ.)(G To G) |
| Weight: | 3.12/3.28Kgs (Typ./Max.) | Designed For: | Desktop Monitor / Industrial / Medical Imaging |
Product Description
29 inch Industrial LCD Display Panels LM290WW2-SSA1 2560*1080
Product details :
Manufacturer:LG Display
Model Name:LM290WW2-SSA1
Screen Size:29.0"
Screen type:LCM, a-Si TFT-LCD
Resolution:2560(RGB)×1080 [CSHD] 96PPI
Pixel configuration:RGB vertical bar
Display size:672.768 × 283.824 mm (H×V)
physical dimension:693.6 × 308.9 × 17.5 mm (H×V×D)
Surface treatment:Matte, Hard coating (3H)
Brightness (cd/m²):250 (Typ.)
Contrast:1000: 1 (Typ.) [Transmission]
Best angle:Full view
Optical mode:IPS, normally black display, transmissive
Viewing angle:89/89/89/89 (Typ.)(CR≥10)
responding speed:14 (Typ.)(G to G) ms
Number of colors:16.7M, 99% sRGB
Backlight type:17S4P WLED, 30K hours, no driver
Screen weight:3.12/3.28Kgs (Typ./Max.)
Refresh rate:60Hz
signal system:LVDS (4 ch, 8-bit), connector, 92 pins
Supply voltage:10.0V (Typ.)
Maximum rating:Storage temperature: -20 ~ 60 °C Working temperature: 0 ~ 50 °C
100% Tested Before Shipping.
We mainly sell Industrial LCD panel and touch screen, provides the product information, technical consultation for all kinds of LCD screen and touch screen, We have many stock parts for 1.5-88 inches is between the various industrial screen, They are applicable to vehicle, medical equipment, injection molding machine ,industrial equipment etc. In addtion to , we also sell Keypad , servo drive and motor , PLC , Encoder ,lcd inverter ...All the products are tested ok before shipping .
Welcome to order!
Kindly Reminder:
If you want to buy more quantiy,please contact us by e-mail or online contact.You can choose the shipping method you prefer.If you buy milti-items,we will give you shipping discount!
Payment:
T/T (Wire Transfer)/Western Union/Paypal ,Escrow,
Shipping and Package :
Shipment:
1.DHL/EMS/UPS/FEDEX/TNT and so on
2.The buyer is responsible for any tax or duty charged by their country.
Return Policy:
1.Please contact us within 7 days if you have any question after you receiving the items.
2.The returned items has to be in its original condition and you must provide us with the shipping tracking number,specific reason for the return,We will issue a return or replacement for your oder after we received the returns.
FAQ :
Q: Can You declare my order of LM290WW2-SSA1 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How to make payment of LM290WW2-SSA1 ?
A: We accept T/T , Paypal , western union .
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: How long will I receive my goods LM290WW2-SSA1 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
