New Original 1366(RGB)×768 18.5 inch LCD Panel display M185XTN01.3

New Original 1366(RGB)×768 18.5 inch LCD Panel display M185XTN01.3

Brand Name: AUO
Model Number: M185XTN01.3
MOQ: 10pcs
Price: Negotiable
Packaging Details: Carton + Foam Cotton
Payment Terms: T/T, Western Union
Detail Information
Place of Origin:
CHINA
Model:
M185XTN01.3
Diagonal Size:
18.5 Inch
Resolution:
1366(RGB)×768 (WXGA) 84PPI
Active Area(mm):
409.8 × 230.4 (H×V)
Outline(mm):
430.4 × 254.6 × 10.4 (H×V×D)
Bezel Area(mm):
413.4 × 234.0 (H×V)
Mass:
1.29Kgs (Typ.)
Application:
Desktop Monitor
Supply Ability:
100000 Unit/Units per Month
Product Description

New Original 1366(RGB)×768 18.5 inch LCD Panel display M185XTN01.3



Product details :

AUO LCD SCREEN M185XTN01.3
Panel Brand AUO
Panel Model M185XTN01.3
Panel Size 17.0 inches
Panel Type a-Si TFT-LCD , LCM
Resolution 1366(RGB)×768, WXGA, 84PPI
Pixel Format RGB Vertical Stripe
Display Area 409.8(W)×230.4(H) mm
Bezel Opening 413.4(W)×234.0(H) mm
Outline Size 430.4(W)×254.6(H)×10.4(D) mm
Surface Matte, Hard coating (3H)
Brightness 200 cd/m² (Typ.)
Contrast Ratio 700:1 (Typ.) (TM)
Viewing Angle 45/45/20/45 (Typ.) (CR≥10)
Display Mode TN, Normally White, Transmissive
Response Time 3.6/1.4 (Typ.)(Tr/Td) ms
Display Colors 16.7M , 74% NTSC
Lamp Type 7S4P WLED , 30K hours, without driver
Frequency 60Hz
Panel Weight 1.29Kgs (Typ.)
Signal Interface LVDS (1 ch, 8-bit) , terminal, 30 pins
Input Voltage 5.0V (Typ.)
Environment Operating: 0 ~ 50 °C ; Storage: -20 ~ 60 °C
