15.6 inch 1366×768 G156XW01 V302 LCD Monitors Touch Screen Display Replacement
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | AUO |
| Model Number: | G156XW01 V302 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton + Foam Cotton |
| Delivery Time: | 5 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Panel Model: | G156XW01 V302 | Panel Size: | 15.6" |
|---|---|---|---|
| Resolution: | 1366(RGB)×768, WXGA, 100PPI | Display Area: | 344.232(W)×193.536(H) Mm |
| Bezel Opening: | 347.54(W)×196.83(H) Mm | Outline Size: | 363.8(W)×215.9(H) ×9.8(D) Mm |
| Surface: | Antiglare, Hard Coating (3H) | Response Time: | 6/2 (Typ.)(Tr/Td) |
| Weight: | 860±40g | Application: | Industry |
Product Description
15.6 inch 1366×768 G156XW01 V302 LCD Monitors Touch Screen Display Replacement
Product details :
| AUO LCD SCREEN G156XW01 V302 | |
| Panel Brand | AUO |
| Panel Model | G156XW01 V302 |
| Panel Size | 15.6 inches |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1366(RGB)×768 WXGA 100PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 344.232 × 193.536 mm (H×V) |
| Bezel Opening | 347.54 × 196.83 mm (H×V) |
| Outline Size | 363.8 × 215.9 × 9.8 mm (H×V×D) |
| Surface | Matte, Hard coating (3H) |
| Brightness | 500 (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) [Transmission |
| Viewing Angle | 85/85/80/80 (Typ.) (CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 6/2 (Typ.)(Tr/Td) ms |
| Display Colors | 16.2M , 65% NTSC |
| Lamp Type | WLED , 50K hours, with LED driver |
| Frequency | 60Hz |
| Panel Weight | 860±40g |
| Signal Interface | LVDS (1 ch, 8-bit) , terminal, 30 pins |
| Input Voltage | 5.0V (Typ.) |
| Environment | Storage temperature: -20 ~ 60 °C Operating temperature: 0 ~ 60 °C |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
Helpful hints:
For Brazilian buyers, if you choose express delivery, such as FED DHL UPS Ect. Be sure to provide the company name and CNPJ number or CPF number.
Please check your message frequently, we may have some questions that you need to confirm before shipping.
Please provide your full name for shipping.
If the product has parameters, please select or indicate when ordering.
Buyers from Chile and Argentina, please provide your tax number so that you can use UPS and other express.
Postal mail is cheap but not fast, especially for some remote countries. If you are in a hurry, please consult a faster method.
If you are shipping by express, please make sure you are not in a remote area, otherwise additional costs will be incurred. Please note that it is shipped remotely: it is collected by Logostics!
Each package has a tracking number. Track here: www.17track.net.
If your items are these, we usually remove standard batteries, liquids and other prohibited parts before shipping. We may ship them via dedicated lines, which will incur additional costs
Duties, customs duties and import costs are the buyer's responsibility. We are not responsible for customs delays or any customs duties, customs duties, value-added tax (VAT) or other charges that may be incurred when you make a purchase. Know your customs policy.
We strive to ensure that every customer is 100% satisfied and solve any problems for you, and always leave positive feedback to all of our customers.
All problems can be solved through communication.
Thank you very much and have a nice day!
If you have any questions, please feel free to contact us. Your question will be answered within 24 hours.
FAQ :
Q: Can You declare my order of G156XW01 V302 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: Can you give me a discount if I need a large quantity of G156XW01 V302 ?
A:Of course!If you make a large order, we will give you a discount.
Q: Can I pay my order of G156XW01 V302 via credit card ?
A:Yes!you can use your credit card through your Paypal account.
Q: How long will I receive my goods G156XW01 V302 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
