C090EAN01.1 40 pins automotive display 9.0 inch tft lcd 1280(RGB)×720 lcd screen module

All Category

Floor Standing Digital Signage

C090EAN01.1 40 pins automotive display 9.0 inch tft lcd 1280(RGB)×720 lcd screen module

Brand Name:	AUO
Model Number:	C090EAN01.1
MOQ:	10pcs
Price:	Negotiable
Packaging Details:	Carton + Foam Cotton
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

C090EAN01.1

Screen Size:

Display Area:

198.72(W)×111.78(H) Mm

Outline Size:

210(W)×126.8(H) Mm

Bezel Opening:

202.02(W)×114.74(H) Mm

Response Time:

15/15 (Max.)(Tr/Td)

Panel Weight:

Application:

Automotive Display

Supply Ability:

888 Unit/Units per Month

Product Description

C090EAN01.1 40 pins automotive display 9.0 inch tft lcd 1280(RGB)×720 lcd screen module

Product details :

AUO LCD SCREEN C090EAN01.1
Manufacturer	AUO
Model Name	C090EAN01.1
Diagonal Size	9.0inches
Type	LCM, a-Si TFT-LCD
Pixel Number	1280(RGB)*720, WXGA, 163PPI
Configuration	RGB Vertical Stripe
Display size	198.72(W)*111.78(H) mm
Viewable area	202.02(W)*114.74(H) mm
physical dimension	210(W)*126.8(H) mm
Surface	Matte
Brightness	680 cd/m² (Typ.)
Contrast Ratio	1000:1 (Typ.) (transmission)
Response Time	15/15 (Max.)(Tr/Td) ms
Viewing Angle	80/80/80/80 (Typ.)(CR≥10)
Operating Mode	AHVA, normally black display, transmissive
Support Color	16.7M, 70% NTSC
Light Source	6S3P WLED, 10K hours, without driver
Frame Rate	60Hz
Appearance style	Medium thickness (PCBA straight, 3.4~4.0mm thick)
Interface Type	LVDS (1 ch, 8-bit), 40 pins, connector
Power Supply	3.3/3.3V (Typ.)(VDD/VDDA)
Environment	Work: -30 ~ 85 °C; Storage: -40 ~ 95 °C; Vibration resistance: 2.9G (28.4 m/s²)

Your parcel will be shipped out within 1-2 workdays after your payment cleared,if orders is made on weekends or holiday,it will be shipped out on Monday or next working day!

Shipping and Package :

C090EAN01.1 40 pins automotive display 9.0 inch tft lcd 1280(RGB)×720 lcd screen module 0

About Package:

We have a professional team to pack it very well to avoid damage,so pls don't worry about the package!

About Return and customs fee:

1.If you buy the wrong items or you don't want the item that you bought,you can return it back to us within 3-5 days,but you should offer the shipping fee.

2.The price don't including the customs fee,if the parcel cause the customs fee,you should pay it by yourself !

3.if you don't get the parcel after the shipping time,you can call the full refund.

About shipping time:

1.China post :It usual takes 15-40 workdays,Brazil will maybe take more days to get the parcel.

2.epacket:It usual takes 10-20 workdays to get the parcel.

3.EMS:It usual takes 7-15 workdays to get the parcels.

4.DHL /Fedex /UPS/TNT:It usual takes 5-7 workdays to get the parcel.

About Warranty period:

We will offer you 3 months warranty,if you have any problems within 3 months after you get your item,you can talk to us,we will try our best to offer you a best solution!

FAQ:

Q: How long is the warranty of C090EAN01.1 ?

A: 90days warranty .

Q: Can you give me a discount if I need a large quantity of C090EAN01.1 ?

A: Of course!If you make a large order, we will give you a discount.

Q: Do you accept sample orders for C090EAN01.1 ?

A: Of course!sample order is welcome !

Q: How long will I receive my goods of C090EAN01.1 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
