G150XAN01.0 15.0 inch tft lcd screen 1024*768 display module LVDS lcd panel
Product Details:
Place of Origin: | China |
Brand Name: | AUO |
Model Number: | G150XAN01.0 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 PCS |
---|---|
Price: | Negotiable |
Packaging Details: | Carton + Foam Cotton |
Delivery Time: | 5 working days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 943PCS |
Detail Information |
|||
Manufacturer: | AUO | Model Name: | G150XAN01.0 |
---|---|---|---|
Screen Size: | 15.0" | Best View On: | Symmetry |
Panel Weight: | 920g (Max.) | Used For: | Industrial |
Product Description
G150XAN01.0 15.0 inch tft lcd screen 1024*768 display module LVDS lcd panel
AUO LCD SCREEN G150XAN01.0 | |
Brand | AUO |
Model | G150XAN01.0 |
Diagonal Size | 15.0 inch |
Type | LCM , a-Si TFT-LCD |
Pixel Format | 1024(RGB)×768 [XGA] 85PPI |
Configuration | RGB Vertical Stripe |
Active Area | 304.128(H)×228.096(V) mm |
Outline Dim. | 326.5(H)×253.5(V) ×9(D) mm |
Bezel Area | 309.9(H)×236.3(V) mm |
Treatment | Antiglare, Hard coating (3H) |
Luminance | 350 cd/m² (Typ.) |
Contrast Ratio | 1000:1 (Typ.) (TM) |
View Direction | Symmetry |
Response Time | 25 (Typ.)(Tr+Td) |
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
Operating Mode | AHVA, Normally Black, Transmissive |
Support Color | 16.2M 60% NTSC |
Light Source | WLED , 50K hours , With LED Driver |
Weight | 920g (Max.) |
Designed For | Industrial |
Frame Rate | 60Hz |
Touch Panel | Without |
Interface Type | LVDS (1 ch, 8-bit) , 20 pins Connector |
Power Supply | 3.3V (Typ.) |
Environment |
Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -20 ~ 70 °C |
