7.0 inch tft lcd screen G070VAN01.0 800×480 lcd screen module
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | G070VAN01.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton + Foam Cotton |
| Delivery Time: | 5 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 943PCS |
|
Detail Information |
|||
| Manufacturer: | AUO | Model Name: | G070VAN01.0 |
|---|---|---|---|
| Screen Size: | 7 Inch | Resolution: | 800×480(RGB) (WVGA) 133PPI |
| Mass: | 175±10%g | Used For: | Industrial |
Product Description
7.0 inch tft lcd screen G070VAN01.0 800×480 lcd screen module
| AUO LCD SCREEN G070VAN01.0 | |
| Manufacturer | AUO |
| Model Name | G070VAN01.0 |
| Screen Size | 7.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 800×480(RGB) (WVGA) 133PPI |
| Arrangement | RGB Horizontal Stripe |
| Active Area | 152.4 × 91.44 (H×V) |
| Outline Dim. | 166.6 × 107 × 10 (H×V×D)166.6 × 107 × 10 (H×V×D) |
| Bezel Area | 154.2 × 93.24 (H×V) |
| Treatment | Antiglare |
| Luminance | 480 cd/m² (Typ.) |
| Contrast Ratio | 1300 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 11/19 (Max.)(Tr/Td) ms11/19 (Max.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | AHVA, Normally Black, Transmissive |
| Color Depth | 262K/16.7M 70% NTSC |
| Backlight | 7S2P WLED , 50K hours , No Driver |
| Mass | 175±10%g |
| Used for | Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
1. 12-month product warranty (excluding man-made damage)
All the goods for sale are in stock, and we can deliver the goods to you within 2 working days.
2. We have many different kinds of goods
What's more, you will get the lowest price with high quality.
Customer Service Policy:
We are more than happy to answer any questions that you have, please contact with
1:Orders processed timely after the payment verification.
2:We only ship to confirmed order addresses. Your order address MUST MATCH your Shipping address.
3:If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction!
4:Due to stock status and time differences, we will choose to ship your item from our first available warehouse for fast delivery.
Terms of Payment:
Payment is safe and convenient. You can pay by credit card (VISA or Mastercard) or other credit card online
Shipment:
1. We can ship goods all over the world, and we have been shipped to many places
For example: Brazil, Russia, France, Iran and so on.
2. The freight is low. We can ship it to you by DHL, Fedex, UPS, EMS and HK Post.
The delivery time (working day) is as follows: Please provide your P.O.Box or postal code address. Countries around.
Q: How do you ship my goods G070VAN01.0 ?
A: We can shipping all over the world.via DHL,UPS,Fedex and EMS.
Q: Are you manufactory or trade company ?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
Q: If I order G070VAN01.0 now,when will you ship the goods ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Do you accept sample orders for AUO G070VAN01.0 ?
A: Of course!sample order is welcome !
