AUO M270HW01 V0 LCD Laptop Screen 1920X1080 FHD 81PPI 30 Pins Connector
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | M270HW01 V0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Manufacturer: | AUO | Model Name: | M270HW01 V0 |
|---|---|---|---|
| Screen Size: | 27 Inch | Resolution: | 1920(RGB)×1080, FHD, 81PPI |
| Display Size: | 597.6(W)×336.15(H) Mm | Brightness: | 300 Cd/m² (Typ.) |
| Display Colors: | 16.7M 72% NTSC | Apply To: | Desktop Monitor |
| High Light: | M270HW01 V0 LCD Laptop Screen,LCD Laptop Screen 1920X1080,NTSC LCD Laptop Screen |
||
Product Description
AUO M270HW01 V0 1920*1080 Desktop LCE SCREEN
Product details :
| AUO LCD SCREEN M270HW01 V0 | |
| Panel Brand | AUO |
| Panel Model | M270HW01 V0 |
| Panel Size | 27.0" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1920(RGB)×1080, FHD, 81PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 597.6(W)×336.15(H) mm |
| Bezel Opening | 603.9(W)×342.15(H) mm |
| Outline Size | 630(W)×368.2(H) ×17.4(D) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 400 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 3.8/1.2 (Typ.)(Tr/Td) |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | 4 pcs CCFL , 50K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Designed For | Desktop Monitor |
| Panel Weight | 3.80Kgs |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| AUO M270HW01 V01920*1080 , FHD, 81PPI 30 pins Connector LCD SCREEN | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
FAQ :
Q: How to order lcd panel M270HW01 V0 ?
A: We accept T/T , PAYPAL , WESTERN UNION.
Q: When will my order 27.0 inch lcd panel M270HW01 V0 ship?
A: The order are shipped within 1-2 working days after received the payment.
Q: Can you test 27.0 inch lcd panel M270HW01 V0 before shipping?
A: Don't Worry , Our AUO lcd M270HW01 V0 was tested ok before shipping
Q: What happen if AUO M270HW01 V0 I received can't work ?
A: Our AUO lcd M270HW01 V0 was tested ok before shipping .If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
Before order:
Before the order, please confirm whether your machine model matching with this LCD screen, if not sure, please contact us
About item and shipping price:
1. For products that are rarely sold or never sold, the item price may not be accurate, please contact me for the correct quote.
2. For remote countries or islands, prices may be inaccurate, high or low, please contact me for the correct quote.
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
