M270HVN02.1 LCD Screen Modules VGA AV 8bit LVDS 1080p LCD With Controller Board
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | M270HVN01.1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Manufacturer: | AUO | Model Name: | M270HVN02.1 |
|---|---|---|---|
| Screen Size: | 27 Inch | Resolution: | 1920(RGB)×1080, FHD, 81PPI |
| Display Size: | 597.6(W)×336.15(H) Mm | Brightness: | 300 Cd/m² (Typ.) |
| Display Colors: | 16.7M 72% NTSC | Apply To: | Desktop Monitor |
| High Light: | M270HVN02.1 lcd Screen modules,AMVA lcd Screen modules,LVDS lcd Screen modules |
||
Product Description
AUO M270HVN02.1 1920*1080 Desktop LCE SCREEN
Product details :
| AUO LCD SCREEN M270HVN02.1 | |
| Panel Brand | AUO |
| Panel Model | M270HVN02.1 |
| Panel Size | 27.0" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1920(RGB)×1080, FHD, 81PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 597.6(W)×336.15(H) mm |
| Bezel Opening | 601.6(W)×340.15(H) mm |
| Outline Size | 630(W)×368.2(H) ×11(D) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 300 cd/m² (Typ.) |
| Contrast Ratio | 3000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | AMVA, Normally Black, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 7/5 (Typ.)(Tr/Td) |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | 15S4P WLED , 30K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Designed For | Desktop Monitor |
| Panel Weight | 2.18Kgs (Typ.) |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| M270HVN02.1 lcd modules universal VGA AV 8bit LVDS 1080p lcd with controller board | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
FAQ :
Q: I do not find the LCD I am looking for in the website, what should I do ?
A: You can give us some pictures,we have a lot of LCD out of shelves.
Q: How long will I receive my goods of M270HVN02.1 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How long is the warranty of M270HVN02.1 ?
A: 90days warranty .
Q: Can you give me a discount if I need a large quantity of M270HVN02.1 ?
A: Of course!If you make a large order, we will give you a discount.
About shipping method:
Due to the continuous impact of the COVID-19 epidemic, the logistics time limit is unstable. Some channels may be suspended at any time or some channels warehouses have a large backlog of goods. We would like to choose which logistics is more stable, fast and safe at certain times for buyer.
Such as buyer choose DHL, we may ship by the same level express like TNT, Fedex or UPS.If you need specified logistics, please tell us in advance.
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
