27 Inch IPS TFT LCD Screen Connector EDP Connector M270HAN02.2 WLED LCD Display Modules
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | M270HAN02.2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Manufacturer: | AUO | Model Name: | M270HAN02.2 |
|---|---|---|---|
| Screen Size: | 27 Inch | Resolution: | 1920(RGB)×1080, FHD, 81PPI |
| Display Size: | 597.888(W)×336.312(H) Mm | Brightness: | 400 Cd/m² (Typ.) |
| Display Colors: | 16.7M 99% NTSC | Apply To: | Desktop Monitor Gaming |
| High Light: | M270HAN02.2 TFT LCD Screen,EDP Connector TFT LCD screen,WLED LCD Display Modules |
||
Product Description
AUO M270HAN02.2 1920*1080 Desktop LCE SCREEN
Product details :
| AUO LCD SCREEN M270HAN02.2 | |
| Panel Brand | AUO |
| Panel Model | M270HAN02.2 |
| Panel Size | 27.0" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1920(RGB)×1080, FHD, 81PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 597.6(W)×336.15(H) mm |
| Outline Size | 609.1(W)×355(H) ×15.6(D) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 400 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | AHVA, Normally Black, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 14 (Typ.)(G to G) |
| Display Colors | 16.7M 99% sRGB |
| Lamp Type | 18S4P WLED , 30K hours , Without Driver |
| Frequency | 144Hz |
| Touch Screen | Without |
| Used for | Desktop Monitor Gaming |
| Panel Weight | 3.22Kgs (Typ.) |
| Signal Interface | eDP (4 Lanes) , HBR1 (2.7G/lane) , 40 pins Connector |
| Input Voltage | 12V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| 27 Inch 1920*1080 resolution IPS TFT Lcd screen connector eDP Connector M270HAN02.2 Display Modules WLED | |
