G185XW01 V1 18.5 Inch LCD Panel 1366X768 WXGA 16.7M 66% NTSC Display Colors
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | G185XW01 V1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | G185XW01 V1 | Diagonal Size: | 18.5inches |
|---|---|---|---|
| Resolution: | 1366(RGB)×768, WXGA, 84PPI | Display Area: | 409.8(W)×230.4(H) Mm |
| Viewing Angle: | 85/85/80/80 (Typ.)(CR≥10) | Display Colors: | 16.7M 66% NTSC |
| High Light: | eDP Connector 18.5 inch lcd panel,16.7M 18.5 inch lcd panel,G185XW01 V1 Industrial LCD Module |
||
Product Description
AUO G185XW01 V1 support 1366*768 LCD screen
Product details :
| AUO LCD SCREEN G185HAN01.3 | |
| Panel Brand | AUO |
| Panel Model | G185HAN01.3 |
| Panel Size | 18.5" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD, 119PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 408.96(W)×230.04(H) mm |
| Outline Size | 428.23(W)×252.87(H) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 500 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Display Mode | AHVA, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | WLED , 50K hours , With LED Driver |
| Frequency | 60Hz |
| Designed For | Industrial |
| Touch Screen | Without |
| Panel Weight | 1.82Kgs (Max.) |
| Signal Interface | eDP Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
| 18.5 inch LCD panel G185HAN01.3 support 1920*1080 500 cd/m lvds input 60HZ LCD screen | |
