LCD Screen Display Panel

M150XS03 V1 AUO LCD Screen 1024x768 TN Normally White Transmissive Display

All Category

Floor Standing Digital Signage

M150XS03 V1 AUO LCD Screen 1024x768 TN Normally White Transmissive Display

Brand Name:	AUO
Model Number:	M150XS03 V1
MOQ:	10pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

M150XS03 V1

Diagonal Size:

15 Inches

Resolution:

1024(RGB)×768, XGA, 85PPI

Display Area:

304.128(W)×228.096(H) Mm

Viewing Angle:

60/60/40/60 (Typ.)(CR≥10)

Display Colors:

262K 60% NTSC

Supply Ability:

100000 Unit/Units per Month

Highlight:

1024x768 AUO LCD Screen

M150XS03 V1 AUO LCD Screen

Transmissive auo lcd display

Product Description

Product details :

AUO LCD SCREEN M150XS03 V1
Panel Brand	AUO
Panel Model	M150XS03 V1
Panel Size	15.0"
Panel Type	a-Si TFT-LCD , LCM
Resolution	1024(RGB)×768, XGA, 85PPI
Pixel Format	RGB Vertical Stripe
Display Area	304.128(W)×228.096(H) mm
Bezel Opening	308.1(W)×232.1(H) mm
Outline Size	331.3(W)×249(H) ×12.1(D) mm
Treatment	Antiglare, Hard coating (3H)
Brightness	240 cd/m² (Typ.)
Contrast Ratio	350:1 (Typ.) (TM)
Viewing Angle	60/60/40/60 (Typ.)(CR≥10)
Work Mode	TN, Normally White, Transmissive
Best View on	6 o'clock
Response Time	8/22 (Typ.)(Tr/Td)
Display Colors	262K 60% NTSC
Lamp Type	2 pcs CCFL ,No Driver
Frequency	60Hz
Used for	Desktop Monitor
Touch Screen	Without
Panel Weight	1.10Kgs (Typ.)
Signal Interface	TTL (2 ch, 6-bit) , 80 pins Connector
Input Voltage	3.3V (Typ.)
Environment	Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
AUO M150XS03 V1 1024*768 a-Si TFT-LCD, LCM TN, Normally White, Transmissive Display

Why Choose Us :

According to customers' various requests,

we can match all accessories which inclusive of driver board,

touch-screen, LED backlight & LVDS cables. TFT LCD,

LCD panel, LCD display,LCD screen, LCD monitor,

LCD module from 2.2 inch to 88 inch.

Quality promised, 100% original,fast delivery,

also enjoy one year guarantee !

Shipping

1, Shipping via AliExpress Standard Shipping.

2, We will send out your goods within 3 working days after we get your order .

3, Normally , you can get the goods within 10-20 calendar days .

4, Please make sure your shipping information ( including address / post code / phone number / contact person ) are correct before order . If you want us send it to another address , pls inform us in advance , and leave message in our transaction.

FAQ

Q: Do you accept the M150XS03 V1 sample order?

A: Yes , sample order is welcome.

Q: How to order if I don’t know the lcd panel number ?

A: You can offer 2-3 photos (back-side and front-side) for your lcd panel ,So that we can check the panel to you.

Q: What does "We may ship a 100% compatible part number for your screen" mean?

A: Because some original screens are not available in the market , So we send the compatible item to you .Don't worry , it is 100% compatible for your screen.

Q: How long is the warranty of M150XS03 V1 ?

A: NEW Product warranty is 90 days , the secondhand goods is 60days.

Shipping and Package :

M150XS03 V1 AUO LCD Screen 1024x768 TN Normally White Transmissive Display 0

1)All of our product will be testing before shipping . So you can be assured the quality of our products

2) All Panels are packed with new and firm carton, capable of long distance transportation.

3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT

4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
