1024x768 TFT AUO LCD Panel M150XN05 V3 RGB Vertical Stripe Hard Coating
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | M150XN05 V3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | M150XN05 V3 | Diagonal Size: | 15 Inches |
|---|---|---|---|
| Resolution: | 1024(RGB)×768, XGA, 85PPI | Display Area: | 304.128(W)×228.096(H) Mm |
| Viewing Angle: | 60/60/40/60 (Typ.)(CR≥10) | Display Colors: | 16.7M 45% NTSC |
| Highlight: | 1024x768 AUO LCD Panel,TFT AUO LCD Panel,M150XN05 V3 AUO LCD Display |
||
Product Description
15inch 1024*768 lcd panel M150XN05 V3 Screen display
Product details :
| AUO LCD SCREEN M150XN05 V3 | |
| Panel Brand | AUO |
| Panel Model | M150XN05 V3 |
| Panel Size | 15.0" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1024(RGB)×768, XGA, 85PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 304.128(W)×228.096(H) mm |
| Bezel Opening | 308.13(W)×232.1(H) mm |
| Outline Size | 326(W)×249(H) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 250 cd/m² (Typ.) |
| Contrast Ratio | 400:1 (Typ.) (TM) |
| Viewing Angle | 60/60/40/60 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 4/12 (Typ.)(Tr/Td) |
| Display Colors | 262K 60% NTSC |
| Lamp Type | 2 pcs CCFL , 30K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Designed For | Desktop Monitor |
| Panel Weight | 1.10Kgs (Typ.) |
| Signal Interface | TTL (2 ch, 6-bit) , 75 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| AUO M150XN05 V3 1024x768 TFT RGB Vertical Stripe LCD Panel Screen Display | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Payment and Shipment
1. We accept Alipay, Western Union, T/T, etc. All major credit cards are accepted through secure payment processor ESCROW
2. Item will be shipped out within 1-3 days.
3. Make sure your address is correct (full name is recommended). We are not responsible for any wrong or undeliverable address.
4. We are not responsible for the possibly additional import duties, remote area charges, taxes or other Customs related fee.
5. Delivery time:
--via DHL, Fedex, UPS: 3-7 working days
--via EMS: 7-15 working days
--via Air Mail or Parcel: 10-30 working days (sometimes longer)
NOTICE: delivery time should not be considered as an aspect of your feedback.
FAQ
Q: How can I trace my order of M150XN05 V3 ?
A: we will give you tracking number then you can trace your order from website.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can I pay my order of M150XN05 V3 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can You declare my order of M150XN05 V3 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
